Netstat

Getting Started

Learn what netstat is and understand the basics of network monitoring

What is Netstat

Understand netstat and its capabilities for network diagnostics

Install and verify netstat installation

Netstat is part of the net-tools package and is available on most Linux systems for network monitoring.

Code

# On Debian/Ubuntu systems
sudo apt-get update
sudo apt-get install net-tools

# On CentOS/RHEL systems
sudo yum install net-tools

# On Fedora systems
sudo dnf install net-tools

# Verify installation
which netstat
netstat --version

Execution

which netstat && echo "Netstat is installed"

Output

/usr/bin/netstat
Netstat is installed

Netstat may not be installed by default on minimal Linux installations
Modern alternative is 'ss' command (comes with iproute2)
Both tools provide similar functionality
Some distributions are phasing out netstat in favor of ss

Netstat overview and capabilities

Netstat provides comprehensive network diagnostics with various flags to show different network information.

Code

# Netstat displays:
# - Active network connections
# - Network interface statistics
# - Routing tables
# - Transport protocol statistics
# - Per-protocol statistics

# Key features:
# - Monitor network connections in real-time
# - Find processes using specific ports
# - Display listening ports and services
# - Analyze network traffic patterns
# - Troubleshoot connectivity issues

# Netstat is a diagnostic tool, not a monitoring daemon
# Run it to get a snapshot of network state at that moment
netstat --help | head -20

Execution

netstat -h | grep -E "^  -[a-z]" | head -10

Output

-a, --all              show both listening and non-listening sockets
-A, --family=FAMILY    Address family (inet|inet6|unix|ipx|ax25|netrom|rose|decnet|x25)
-B, --sbufsize=SIZE    show both listening and non-listening sockets
-c, --continuous       continuous listing
-e, --extend           show additional information

Each flag can be combined with others for detailed analysis
Use -h or --help to see all available options
Netstat output can be very large on systems with many connections
Combine with grep for filtering results

Core Concepts

Understand basic netstat terminology and network concepts

Understand netstat output columns and fields

Understanding netstat column headers helps interpret network connection details accurately.

Code

# Netstat output columns explained:
# Proto: Protocol (tcp, udp, unix)
# Recv-Q: Bytes in receive queue
# Send-Q: Bytes in send queue
# Local Address: Local IP:Port
# Foreign Address: Remote IP:Port
# State: Connection state
# PID/Program name: Process using the connection

# Example interpretation:
# tcp  0  0  127.0.0.1:3306  0.0.0.0:*  LISTEN  1234/mysqld
# This means MySQL is listening on port 3306 (PID 1234)

netstat -tln | head -5

Execution

netstat -an | head -3 && echo "..." && netstat -an | tail -3

Output

Active Internet connections (servers and established)
Proto Recv-Q Send-Q Local Address           Foreign Address         State
tcp        0      0 0.0.0.0:22              0.0.0.0:*               LISTEN
...
tcp        0      0 192.168.1.100:55432    10.0.0.50:443           ESTABLISHED

Recv-Q and Send-Q show bytes waiting to be processed
State column shows connection lifecycle stage
PID/Program name requires root/sudo privileges with -p flag
Foreign Address shows remote connection endpoint

Understand connection states and transmission protocol

Connection states are part of the TCP state machine; UDP connections don't have states since it's connectionless.

Code

# Common connection states:
# LISTEN - Socket is waiting for incoming connections
# ESTABLISHED - Connection is active and data is flowing
# SYN_SENT - Waiting for matching connection request
# SYN_RECV - Received connection request, waiting for acknowledgment
# TIME_WAIT - Connection closed, waiting for remaining packets
# CLOSE_WAIT - Remote end closed, waiting for local close
# LAST_ACK - Waiting for acknowledgment of connection close
# CLOSED - Connection is closed
# CLOSE - Initiating close on socket

# TCP provides reliable, ordered delivery (LISTEN, ESTABLISHED, etc)
# UDP is connectionless (no STATE field in netstat -u output)

netstat -an | grep ESTABLISHED | head -3

Execution

netstat -an | grep -E "^tcp|^udp" | head -5

Output

tcp        0      0 0.0.0.0:22              0.0.0.0:*               LISTEN
tcp        0      0 127.0.0.1:631          0.0.0.0:*               LISTEN
tcp6       0      0 :::22                   :::*                    LISTEN
udp        0      0 0.0.0.0:68              0.0.0.0:*
udp        0      0 0.0.0.0:5353            0.0.0.0:*

Different states indicate different stages of connection lifecycle
TIME_WAIT connections are normal and eventually expire
CLOSE_WAIT can indicate zombie processes or unresponsive clients
UDP doesn't maintain connection state

Modern Alternatives

Modern tools that replace netstat functionality

Use ss command instead of netstat

The ss command is the preferred modern alternative to netstat with better performance and features.

Code

# ss (socket statistics) is the modern replacement for netstat
# ss is faster and provides more detailed information
# ss comes with iproute2 package (usually pre-installed)

# Show all listening sockets
ss -tln

# Show all TCP connections
ss -ta

# Show specific port
ss -tln | grep :8080

# Show process names (requires sudo)
sudo ss -tlnp | grep :80

Execution

which ss && echo "ss command is available"

Output

/usr/sbin/ss
ss command is available

ss uses the same flags as netstat
ss is faster because it reads from /proc/net directly
ss shows more detailed information (timer info, congestion window)
Both tools can be used interchangeably in most cases

Compare netstat and ss output

Both netstat and ss provide network statistics, with ss being the faster modern option.

Code

# Both commands show similar information
# netstat output:
# Proto Recv-Q Send-Q Local Address  Foreign Address  State
# tcp   0      0      0.0.0.0:22     0.0.0.0:*        LISTEN

# ss output includes additional details:
# State  Recv-Q Send-Q Local Address:Port  Peer Address:Port
# LISTEN 0      128    0.0.0.0:22         0.0.0.0:*

# Performance comparison:
# netstat scans /proc/net files
# ss uses netlink sockets (faster)

echo "=== Using netstat ===" && netstat -tln | head -2
echo "=== Using ss ===" && ss -tln | head -2

Execution

netstat -tln | head -2 && echo "---" && ss -tln | head -2

Output

Active Internet connections (only servers)
Proto Recv-Q Send-Q Local Address           Foreign Address         State
---
State  Recv-Q Send-Q Local Address:Port              Peer Address:Port
LISTEN 0      128    0.0.0.0:22                     0.0.0.0:*

ss is recommended for new scripts and tools
netstat is still useful for compatibility
Some systems only have ss installed
Learn both for comprehensive network administration

Basic Usage

Master essential netstat commands for displaying connections

Show All Connections

Display all network connections on the system

Display all network connections

The -a flag shows all connections (both listening and established), while -n displays numeric addresses.

Code

# Show all connections (listening and established)
netstat -a

# Show only TCP connections
netstat -at

# Show only UDP connections
netstat -au

# Show all with numeric IP addresses
netstat -an

# Show all with program names
sudo netstat -ap

Execution

netstat -an | head -5

Output

Active Internet connections (servers and established)
Proto Recv-Q Send-Q Local Address           Foreign Address         State
tcp        0      0 127.0.0.1:631          0.0.0.0:*               LISTEN
tcp        0      0 0.0.0.0:22              0.0.0.0:*               LISTEN
tcp6       0      0 :::22                   :::*                    LISTEN

Use -a to see complete network picture
-n is faster than resolving hostnames
Combine -a with -n for numeric all connections
Output can be very large on systems with many connections

Show connections with detailed information

Extended flags provide additional details about connections, useful for diagnostics and analysis.

Code

# Extended information about all connections
netstat -ae

# Very detailed information
netstat -aee

# All connections sorted by state
netstat -a | sort -k6

# Count connections by type
netstat -an | grep -c "ESTABLISHED"

# Show connections with timestamps
netstat -ae | grep -v "^Active"

Execution

netstat -a | wc -l

Output

-e flag shows ethernet statistics
-ee shows even more extended information
Useful for filtering and analyzing specific connection types
Can be piped to grep and other tools for filtering

List Listening Ports

Display ports that are actively listening for connections

Show all listening ports and services

The -l flag shows only listening sockets, useful for discovering what services are active on a system.

Code

# Show all listening sockets (listening only)
netstat -l

# Show listening TCP ports
netstat -lt

# Show listening UDP ports
netstat -lu

# Show listening with numeric output
netstat -ln

# Show listening with process information
sudo netstat -lnp

Execution

netstat -ln | grep -E "LISTEN|Proto"

Output

Proto Recv-Q Send-Q Local Address           Foreign Address         State
tcp        0      0 127.0.0.1:631          0.0.0.0:*               LISTEN
tcp        0      0 0.0.0.0:22              0.0.0.0:*               LISTEN
tcp6       0      0 :::22                   :::*                    LISTEN
udp        0      0 0.0.0.0:68              0.0.0.0:*

-l shows listening ports only
Combine with -n for numeric output
Use -p to see which process is listening
Requires sudo for -p flag to show all processes

Find specific listening services

Using grep with netstat helps identify specific listening services and their process IDs.

Code

# Show listening services with process names
sudo netstat -lnp

# Show only HTTP and HTTPS listeners
sudo netstat -lnp | grep -E ":80\s|:443\s"

# Show listening ports in numeric form
netstat -ln | grep -E "LISTEN|Proto"

# Check if specific port is listening
sudo netstat -lnp | grep ":8080"

# List all listening TCP ports sorted
netstat -ln | grep tcp | grep LISTEN | sort -k4

Execution

sudo netstat -lnp | grep -E ":22 " | head -3

Output

tcp        0      0 0.0.0.0:22              0.0.0.0:*               LISTEN      1234/sshd
tcp6       0      0 :::22                   :::*                    LISTEN      1234/sshd

-p flag requires root/sudo privileges
Useful for auditing open ports
Shows PID and program name for each service
Can be used for security verification

Protocol-Specific Display

Show connections for specific network protocols

Display TCP and UDP connections separately

Filter connections by protocol type to focus on specific communication types (TCP for reliable, UDP for fast).

Code

# Show only TCP connections
netstat -t

# Show only TCP with numeric output
netstat -tn

# Show only UDP connections
netstat -u

# Show only UDP with numeric output
netstat -un

# Show TCP established connections only
netstat -t | grep ESTABLISHED

# Show UDP with extended info
netstat -ue

Execution

netstat -tn | grep ESTABLISHED | wc -l

Output

TCP connections show state information
UDP is stateless (no connection states shown)
-t flag for TCP, -u flag for UDP
Combine with -l for listening ports of specific protocol

Show both IPv4 and IPv6 connections

Different address families (inet/inet6) can be filtered separately to analyze specific connection types.

Code

# Show all internet connections (IPv4 and IPv6)
netstat -A inet,inet6 -an

# Show IPv4 TCP only
netstat -A inet -tn

# Show IPv6 TCP only
netstat -A inet6 -tn

# Show connections and exclude IPv6
netstat -A inet -an

# Show dual-stack listening (both IPv4 and IPv6)
netstat -ln | grep -E "tcp|tcp6"

Execution

netstat -A inet -tn | head -4

Output

Active Internet connections (w/o servers)
Proto Recv-Q Send-Q Local Address           Foreign Address         State
tcp        0      0 192.168.1.100:55432    203.0.113.50:443        ESTABLISHED

inet is IPv4, inet6 is IPv6
Some services listen on both IPv4 and IPv6
tcp6 indicates IPv6 TCP connections
Can be used for network troubleshooting

Finding Connections and Ports

Locate specific connections, ports, and processes

Find Listening Port

Discover which process is using a specific port

Find process listening on specific port

The -p flag shows process ID and name, allowing identification of services using specific ports.

Code

# Find what's listening on port 8080
sudo netstat -tlnp | grep :8080

# Find what's listening on port 443
sudo netstat -tlnp | grep :443

# Find process on any port
sudo netstat -tlnp | grep -E ":80 |:443 |:3306 "

# Show all listening ports with processes
sudo netstat -tlnp | grep LISTEN

# Find IPv4 listeners on port 3000
sudo netstat -tlnp | grep :3000

Execution

sudo netstat -tlnp | grep ssh | head -2

Output

tcp        0      0 0.0.0.0:22              0.0.0.0:*               LISTEN      1234/sshd
tcp6       0      0 :::22                   :::*                    LISTEN      1234/sshd

-p flag requires sudo/root privileges
Useful for port conflict resolution
Shows both IPv4 and IPv6 listeners
PID can be used with kill to terminate the process

Find all connections from specific IP

Filtering netstat output by IP address helps locate connections from specific hosts or networks.

Code

# Find all connections to specific IP
netstat -an | grep 192.168.1.100

# Find connections to specific remote IP
netstat -an | grep 203.0.113.50

# Find all connections from specific port
netstat -an | grep ":8080 "

# Find connections to specific port on remote
netstat -an | grep " :443"

# Combine source and destination filters
netstat -an | grep "192.168" | grep "ESTABLISHED"

Execution

netstat -an | grep 127.0.0.1 | head -3

Output

tcp        0      0 127.0.0.1:631          0.0.0.0:*               LISTEN
tcp        0      0 127.0.0.1:25            0.0.0.0:*               LISTEN
unix  2      [ ]     DGRAM                    3456     @/tmp/var/run/user/1000

Use numeric output (-n) for faster filtering
Combine multiple grep conditions for precise filtering
Useful for security analysis and traffic auditing
Can identify unauthorized connections

Connections by Process

Show all connections associated with specific processes

Show connections for specific process

The -p flag allows filtering connections by process name or PID for application-specific analysis.

Code

# Show all nginx connections
sudo netstat -anp | grep nginx

# Show all MySQL database connections
sudo netstat -anp | grep mysql

# Show all SSH connections
sudo netstat -anp | grep sshd

# Show connections by PID
sudo netstat -anp | grep " 1234/

# List unique processes with connections
sudo netstat -anp | grep -oE '[0-9]+/[a-z]' | sort -u

Execution

sudo netstat -anp | grep sshd | head -2

Output

tcp        0      0 0.0.0.0:22              0.0.0.0:*               LISTEN      1234/sshd
tcp        0      128 192.168.1.100:22       192.168.1.50:55234     ESTABLISHED 1234/sshd

Requires sudo/root for -p flag
Useful for application performance analysis
Can identify connection leaks or excessive connections
Helps monitor multi-process applications

Analyze connection statistics by process

Using awk and sort with netstat helps aggregate statistics and identify problematic connection patterns.

Code

# Count connections per process
sudo netstat -anp | tail -n +3 | awk '{print $NF}' | sort | uniq -c | sort -rn

# Find process with most connections
sudo netstat -anp | tail -n +3 | awk '{print $NF}' | sort | uniq -c | sort -rn | head -1

# Show established connections per process
sudo netstat -anp | grep ESTABLISHED | awk '{print $NF}' | sort | uniq -c | sort -rn

# Find orphaned connections
sudo netstat -anp | grep "CLOSE_WAIT" | awk '{print $NF}' | sort -u

Execution

sudo netstat -anp 2>/dev/null | grep LISTEN | wc -l

Output

Useful for debugging connection leaks
Identifies most active processes
Can detect stuck connections
Helps optimize application performance

Established Connections

Focus on active data-transfer connections

Show only established connections

Filtering for ESTABLISHED connections shows only active data-transfer connections, excluding listening sockets.

Code

# Show all established connections
netstat -an | grep ESTABLISHED

# Show established with process info
sudo netstat -anp | grep ESTABLISHED

# Count established connections
netstat -an | grep ESTABLISHED | wc -l

# Show established TCP connections only
netstat -tn | grep ESTABLISHED

# Monitor established connections to specific port
sudo netstat -anp | grep ":443" | grep ESTABLISHED

Execution

netstat -an | grep ESTABLISHED | wc -l

Output

ESTABLISHED means active connection with data flowing
Useful for monitoring active connections
Helps identify connection hangs by their absence
Can be monitored continuously for real-time activity

Monitor active connections with details

Advanced filtering and awk processing allows detailed analysis of established connections by remote host.

Code

# Show established connections with full details
sudo netstat -anpe | grep ESTABLISHED

# Show established by remote host
netstat -an | grep ESTABLISHED | awk '{print $5}' | cut -d: -f1 | sort | uniq -c

# List established connections with packet counts
sudo netstat -anp | grep ESTABLISHED | awk '{print $4, $5, $NF}'

# Monitor specific established connection
sudo netstat -anp | grep ESTABLISHED | grep 203.0.113.50

# Track connection duration (using state history)
watch -n 1 'netstat -an | grep ESTABLISHED | wc -l'

Execution

netstat -an | grep ESTABLISHED | awk '{print $5}' | head -3

Output

203.0.113.50:443
203.0.113.51:443
203.0.113.52:443

Use awk for programmatic filtering
Can be piped to other commands for analysis
watch command enables real-time monitoring
Useful for identifying connection patterns

Connection States

Understand and analyze TCP connection states

TCP States Explained

Detailed explanation of TCP connection state lifecycle

Understand TCP connection states

TCP states represent different stages of connection lifecycle, from establishment to termination.

Code

# LISTEN - Waiting for incoming connections
# Port is open and actively listening for connections
# Used by server applications

# SYN_SENT - Initial connection request sent
# Waiting for acknowledgment from remote host
# Usually very brief state

# SYN_RECV - Connection request received and acknowledged
# Waiting for acknowledgment back
# Rare to see in netstat output

# ESTABLISHED - Active data transfer
# Connection is open and both sides exchange data
# Most common state for active connections

# FIN_WAIT_1 - Waiting for connection close
# Local side initiated close
# Waiting for acknowledgment

# FIN_WAIT_2 - Waiting for remote close
# Local side closed sending
# Waiting for remote side to close

netstat -an | grep -E "LISTEN|ESTABLISHED|TIME_WAIT" | head -10

Execution

netstat -an | grep -o -E "LISTEN|ESTABLISHED|TIME_WAIT" | sort | uniq -c

Output

3 ESTABLISHED
5 LISTEN
12 TIME_WAIT

Each state has specific meaning and transition rules
States are defined in TCP state machine (RFC 793)
Some states are transient and rarely seen
Understanding states helps with network troubleshooting

Show connections in specific states

Specific state filtering reveals connection patterns and potential networking issues on the system.

Code

# Show TIME_WAIT connections (waiting to close)
netstat -an | grep TIME_WAIT

# Show CLOSE_WAIT connections (remote closed)
netstat -an | grep CLOSE_WAIT

# Show all non-listening connections
netstat -an | grep -v LISTEN | grep -v "^Proto"

# Show only listening ports
netstat -an | grep LISTEN

# Count connections by state
netstat -an | grep -oE "LISTEN|ESTABLISHED|TIME_WAIT|CLOSE_WAIT" | sort | uniq -c

Execution

netstat -an | grep CLOSE_WAIT | wc -l

Output

TIME_WAIT connections are normal cleanup
CLOSE_WAIT indicates unclosed sockets
Many TIME_WAIT connections can be investigation point
Use for performance analysis

Timeout and Waiting States

Analyze timeout and waiting connection states

Monitor TIME_WAIT connections

TIME_WAIT is a normal TCP state for graceful connection termination and preventing packet confusion.

Code

# TIME_WAIT is normal post-connection cleanup state
# Connection is closed but local port still in use
# Exists to prevent packet confusion

# Show all TIME_WAIT connections
netstat -an | grep TIME_WAIT

# Count TIME_WAIT by remote host
netstat -an | grep TIME_WAIT | awk '{print $5}' | cut -d: -f1 | sort | uniq -c

# Show TIME_WAIT connections in details
sudo netstat -anp | grep TIME_WAIT

# Count TIME_WAIT per second (monitor trend)
watch -n 1 'netstat -an | grep TIME_WAIT | wc -l'

Execution

netstat -an | grep TIME_WAIT | wc -l

Output

TIME_WAIT lasts 2 MSL (Maximum Segment Lifetime)
Default is often 60 seconds
Many TIME_WAIT is normal for servers
Can be tuned with kernel parameters if excessive

Identify and analyze CLOSE_WAIT connections

CLOSE_WAIT connections indicate the remote side closed but the local application hasn't closed its socket.

Code

# CLOSE_WAIT means remote closed but local still open
# Usually indicates application bug with unclosed sockets
# Can lead to resource leaks if not addressed

# Show all CLOSE_WAIT connections
netstat -an | grep CLOSE_WAIT

# Show CLOSE_WAIT with process info
sudo netstat -anp | grep CLOSE_WAIT

# Find which application has CLOSE_WAIT
sudo netstat -anp | grep CLOSE_WAIT | awk '{print $NF}' | sort | uniq -c

# Monitor CLOSE_WAIT count
watch -n 5 'netstat -an | grep CLOSE_WAIT | wc -l'

# List all CLOSE_WAIT connections details
sudo netstat -anpe | grep CLOSE_WAIT

Execution

sudo netstat -anp | grep CLOSE_WAIT | head -2

Output

tcp        0      0 192.168.1.100:55432    203.0.113.60:3306     CLOSE_WAIT  5678/python
tcp        0      0 192.168.1.100:55433    203.0.113.61:3306     CLOSE_WAIT  5678/python

CLOSE_WAIT accumulation suggests application bug
Applications should close sockets properly
Common in poorly-written database client code
Requires application fix, not system configuration

Connection Flow Analysis

Analyze full connection flow and state transitions

Analyze connection flow states

Analyzing the distribution of connection states reveals network health and potential bottlenecks.

Code

# Connections follow this general flow:
# Client: CLOSED -> SYN_SENT -> ESTABLISHED -> FIN_WAIT_1 -> FIN_WAIT_2 -> CLOSED
# Server: LISTEN -> SYN_RECV -> ESTABLISHED -> CLOSE_WAIT -> LAST_ACK -> CLOSED

# Normal healthy flow shows mostly LISTEN and ESTABLISHED
netstat -an | awk '{print $NF}' | sort | uniq -c | sort -rn | head -10

# Check for abnormal accumulation of states
netstat -an | grep -E "SYN_SENT|SYN_RECV" | wc -l

# Show connection setup rate
watch -n 1 'netstat -an | grep ESTABLISHED | wc -l'

Execution

netstat -an | tail -n +3 | awk '{print $NF}' | sort | uniq -c | sort -rn | head -5

Output

4 LISTEN
3 ESTABLISHED
2 TIME_WAIT
1 CLOSE_WAIT

Mostly LISTEN and ESTABLISHED is healthy
Many SYN states indicates port scanning or DDoS
Many CLOSE_WAIT indicates application bugs
Monitor trends over time for anomalies

Detect and diagnose connection issues

Investigating abnormal connection states helps identify attacks, bugs, or network issues.

Code

# Excessive SYN_SENT might indicate port scanning attack
netstat -an | grep SYN_SENT

# Excessive SYN_RECV indicates half-open connections (SYN flood)
netstat -an | grep SYN_RECV | wc -l

# Stuck connections in FIN_WAIT state
netstat -an | grep FIN_WAIT

# Reset connections (LAST_ACK)
netstat -an | grep LAST_ACK | wc -l

# Full diagnostic report
echo "=== Connection State Summary ===" && \
netstat -an | tail -n +3 | awk '{print $NF}' | sort | uniq -c | sort -rn

Execution

netstat -an | grep SYN_SENT | wc -l

Output

SYN_SENT indicates client attempting connection
Many SYN_SENT from single source indicates attack
FIN_WAIT indicates normal closure
Monitor for abnormal patterns

Network Statistics and Analysis

Display and analyze network statistics and routing information

Network Statistics

Show protocol-level statistics and metrics

Display protocol statistics

TCP statistics show connection attempts, retransmissions, and error rates for protocol-level diagnostics.

Code

# Show statistics for all protocols
netstat -s

# Show TCP statistics only
netstat -st

# Show UDP statistics only
netstat -su

# Show ICMP statistics (ping errors)
netstat -si

# Show statistics for specific protocol
netstat -sp tcp

Execution

netstat -st | head -15

Output

Tcp:
    4567 active connections openings
    1234 passive connection openings
    89 failed connection attempts
    2 connection resets received
    5 connections established
    234567 segments received
    234567 segments sent out
    45 segments retransmitted
    0 bad segments received
    89 resets sent
    156 packets received
    234 packets to unknown port received

Active openings = connections initiated by this system
Passive openings = connections received from others
Failed attempts indicate connection problems
Retransmissions indicate packet loss or latency

Analyze connection and packet statistics

Analyzing connection statistics helps understand network activity patterns and identify performance issues.

Code

# Show statistics for TCP connections
netstat -s | grep -A 20 "^Tcp:"

# Show packet loss indicators
netstat -s | grep -i "segment"

# Show connection attempt statistics
netstat -s | grep -i "active\|passive\|failed"

# Show error statistics
netstat -s | grep -i "error\|reset\|bad"

# Compare TCP vs UDP traffic
echo "=== TCP ===" && netstat -st | grep packets \
&& echo "=== UDP ===" && netstat -su | grep packets

Execution

netstat -s | grep "active connections"

Output

4567 active connections openings

High retransmission rates indicate network problems
Failed connection attempts suggest unreachable services
Compare statistics over time to detect trends
Use for performance baseline and anomaly detection

Routing Table

Display and analyze network routing information

Display system routing table

Routing table shows how packets are directed to their destinations based on destination IP address.

Code

# Show routing table
netstat -r

# Show routing table with numeric output
netstat -rn

# Show IPv4 routing table only
netstat -rn -A inet

# Show IPv6 routing table
netstat -rn -A inet6

# Show routing details with extended info
netstat -re

Execution

netstat -rn | head -8

Output

Kernel IP routing table
Destination     Gateway         Genmask         Flags Metric Ref    Use Iface
default         192.168.1.1     0.0.0.0         UG    100    0        0 eth0
192.168.1.0     0.0.0.0         255.255.255.0   U     256    0        0 eth0
172.17.0.0      0.0.0.0         255.255.0.0     U     0      0        0 docker0

Destination: Target network or 'default' for fallback
Gateway: Next hop router (0.0.0.0 means direct interface)
Genmask: Subnet mask for the route
Flags: U=up, G=gateway, H=host-specific

Analyze and troubleshoot routes

Default gateway and route analysis helps troubleshoot connectivity issues and understand network structure.

Code

# Show all routes with metrics
netstat -rn | grep -v "^Kernel"

# Show default gateway
netstat -rn | grep "^default"

# Show specific network routes
netstat -rn | grep "192.168"

# Count routes per interface
netstat -rn | awk '{print $NF}' | sort | uniq -c

# Show routes sorted by interface
netstat -rn | sort -k 5

Execution

netstat -rn | grep "^default"

Output

default         192.168.1.1     0.0.0.0         UG    100    0        0 eth0

0.0.0.0 gateway means direct connection (no routing needed)
Multiple gateways indicate complex routing
Metric indicates route preference
Use for detecting misconfigured routes

Interface Statistics

Display network interface statistics and metrics

Show network interface statistics

Interface statistics show packet counts, errors, and dropped packets for each network interface.

Code

# Show interface statistics
netstat -i

# Show interface statistics with extended info
netstat -ie

# Show very detailed interface information
netstat -iee

# Show interface MTU and other details
netstat -ie | head -10

# Format output for readability
netstat -i | column -t

Execution

netstat -i | head -5

Output

Kernel Interface table
Iface      MTU    RX-OK RX-ERR RX-DRP RX-OVR    TX-OK TX-ERR TX-DRP TX-OVR Flg
docker0   1500 34567890      0      0      0  234567      0      0      0 BMRU
eth0      1500 987654321      0      5      0 2345678      0      3      0 BMRU

RX-OK: Packets received successfully
TX-OK: Packets transmitted successfully
RX-ERR/TX-ERR: Transmission errors
RX-DRP/TX-DRP: Dropped packets

Analyze interface health and performance

Detailed analysis of per-interface statistics helps identify problematic network interfaces or links.

Code

# Show detailed interface information
netstat -ie

# Extract interface errors
netstat -i | awk '{print $1, $3, $4}'

# Check for packet loss
netstat -i | awk '{if (NR>2 && $4>0) print $1, "has errors"}'

# Show interfaces with dropped packets
netstat -i | awk '{if (NR>2 && $5>0) print $1, "dropped:", $5}'

# Calculate error rates
netstat -i | awk '{if (NR>2) print $1, "RX:", $3, "Errors:", $4}'

Execution

netstat -i | grep -E "^eth0|^Iface"

Output

Kernel Interface table
eth0      1500 987654321      0      5      0 2345678      0      3      0 BMRU

Any errors indicate potential network problems
Dropped packets suggest buffer overflow or network congestion
MTU mismatch can cause dropping
Monitor trends for early issue detection

Continuous Monitoring

Monitor network statistics and connections in real-time

Monitor network activity continuously

Continuous monitoring with netstat -c or watch reveals real-time network activity and trends.

Code

# Monitor connections with continuous updates
netstat -c

# Monitor specific metric (using watch command)
watch -n 1 'netstat -an | grep ESTABLISHED | wc -l'

# Watch listening ports for changes
watch -n 5 'netstat -tlnp'

# Monitor interface counters
watch -n 1 'netstat -i'

# Track connection count trend
for i in {1..5}; do echo "Count: $(netstat -an | grep ESTABLISHED | wc -l)"; sleep 1; done

Execution

netstat -c --count=3

Output

Active Internet connections (w/o servers)
Proto Recv-Q Send-Q Local Address           Foreign Address         State
tcp        0      0 192.168.1.100:60123    203.0.113.5:443         ESTABLISHED
tcp        0      128 192.168.1.100:22       192.168.1.50:55234     ESTABLISHED

Active Internet connections (w/o servers)
Proto Recv-Q Send-Q Local Address           Foreign Address         State

-c flag causes netstat to refresh frequently
watch command provides nicer formatted output
Useful for performance testing and diagnostics
Can be combined with other tools for alerting

Create monitoring scripts

Custom monitoring scripts can automate tracking and alerting for connection anomalies.

Code

# Monitor and alert on connection count
#!/bin/bash
THRESHOLD=1000
while true; do
  COUNT=$(netstat -an | grep ESTABLISHED | wc -l)
  if [ $COUNT -gt $THRESHOLD ]; then
    echo "Alert: $COUNT established connections (threshold: $THRESHOLD)"
  fi
  sleep 60
done

# Log connection statistics hourly
#!/bin/bash
while true; do
  echo "$(date): $(netstat -an | grep ESTABLISHED | wc -l) connections" >> connections.log
  sleep 3600
done

Execution

netstat -an 2>/dev/null | grep ESTABLISHED | wc -l

Output

Scripts can monitor thresholds and alert
Useful for production system monitoring
Can log data for capacity planning
Integrate with monitoring systems

Practical Examples and Troubleshooting

Real-world use cases and troubleshooting techniques

Find Process Using Port

Identify which process is bound to a specific port

Find process listening on specific port

Using grep with specific port number finds the listening process, showing PID and program name.

Code

# Find what process is using port 8080
sudo netstat -tlnp | grep :8080

# Alternative: Use grep to extract process name
PROCESS=$(sudo netstat -tlnp | grep :8080 | awk '{print $NF}')
echo "Port 8080 is used by: $PROCESS"

# Show complete process command line
PID=$(sudo netstat -tlnp | grep :8080 | awk '{print $NF}' | cut -d/ -f1)
ps aux | grep $PID

# List multiple ports at once
for port in 80 443 3306 5432; do
  echo -n "Port $port: "
  sudo netstat -tlnp | grep ":$port " | awk '{print $NF}'
done

Execution

sudo netstat -tlnp | grep 22 | head -1

Output

tcp        0      0 0.0.0.0:22              0.0.0.0:*               LISTEN      1234/sshd

Requires sudo/root for -p flag
PID can be used with ps or ps aux for details
Useful for resolving port conflicts
Can be automated in scripts

Kill process using specific port

Extracting PID from netstat output allows programmatic process termination when needed.

Code

# Find and kill process on port 8080
PID=$(sudo netstat -tlnp | grep :8080 | awk '{print $NF}' | cut -d/ -f1)
if [ ! -z "$PID" ]; then
  echo "Killing process $PID on port 8080"
  sudo kill -9 $PID
else
  echo "No process found on port 8080"
fi

# One-liner to kill process on port
sudo kill -9 $(sudo netstat -tlnp | grep :8080 | awk '{print $NF}' | cut -d/ -f1)

# Graceful kill (SIGTERM first, then SIGKILL)
PID=$(sudo netstat -tlnp | grep :8080 | awk '{print $NF}' | cut -d/ -f1)
sudo kill $PID && sleep 2 && sudo kill -9 $PID 2>/dev/null

Execution

sudo netstat -tlnp | grep -E ":80 |:443 " | head -2

Output

tcp        0      0 0.0.0.0:80              0.0.0.0:*               LISTEN      5678/nginx
tcp        0      0 0.0.0.0:443             0.0.0.0:*               LISTEN      5678/nginx

Always use graceful shutdown first (SIGTERM)
SIGKILL (-9) should be last resort
Terminate wrong process can cause data loss
Better to use service/systemctl commands when possible

Monitor Port Changes Over Time

Track changes to listening ports and active connections

Track listening port changes

Comparing netstat snapshots over time helps detect unauthorized services or security changes.

Code

# Create initial port list
sudo netstat -tlnp > /tmp/ports_before.txt

# After some time, compare
sudo netstat -tlnp > /tmp/ports_after.txt
diff /tmp/ports_before.txt /tmp/ports_after.txt

# Monitor for new services appearing
sudo netstat -tlnp | grep -v "LISTEN" | wc -l

# Create baseline of listening services
echo "=== Baseline at $(date) ===" >> port_baseline.log
sudo netstat -tlnp | grep LISTEN >> port_baseline.log

# Check for unexpected open ports
sudo netstat -tlnp | grep -v "ssh\|sshd"

Execution

sudo netstat -tlnp 2>/dev/null | wc -l

Output

Use cron to periodically capture port state
Baseline helps identify anomalies
Useful for security audits
Can trigger alerts on changes

Monitor connection count trends

Continuous tracking of connection counts reveals usage patterns and capacity planning needs.

Code

# Log connection counts hourly
*/60 * * * * echo "$(date +\%Y-\%m-\%d\ \%H:\%M:\%S),$(netstat -an | grep ESTABLISHED | wc -l)" >> connections.csv

# Script to collect statistics over time
#!/bin/bash
for i in {1..60}; do
  ESTABLISHED=$(netstat -an | grep ESTABLISHED | wc -l)
  TIME=$(date "+%Y-%m-%d %H:%M:%S")
  echo "$TIME: $ESTABLISHED"
  (( i < 60 )) && sleep 60
done > connection_trends.log

# Analyze connection growth
tail -50 connections.csv | awk -F',' '{print $NF}' | sort -n

Execution

netstat -an 2>/dev/null | grep ESTABLISHED | wc -l

Output

Use cron for automated periodic collection
Store in database or CSV for analysis
Identify peak times and growth trends
Use for performance tuning

Diagnose Connection Hangs

Identify and analyze stuck or hanging connections

Identify hanging connections

Analyzing non-standard states reveals connections stuck in cleanup or waiting states.

Code

# Show connections not in ESTABLISHED or LISTEN state
netstat -an | grep -v ESTABLISHED | grep -v LISTEN | grep -E "^tcp|^udp"

# Show CLOSE_WAIT connections (remote closed but local open)
netstat -an | grep CLOSE_WAIT

# Show FIN_WAIT connections (waiting for close to complete)
netstat -an | grep FIN_WAIT

# Identify which process has hanging connections
sudo netstat -anp | grep CLOSE_WAIT | awk '{print $NF}' | sort -u

# Check for TIME_WAIT accumulation (possible port exhaustion)
netstat -an | grep TIME_WAIT | wc -l

Execution

sudo netstat -anp | grep -E "CLOSE_WAIT|FIN_WAIT" | head -3

Output

tcp        0      0 192.168.1.100:55234    203.0.113.100:3306     CLOSE_WAIT  5678/app

CLOSE_WAIT indicates application bug
FIN_WAIT is normal but excessive amount unusual
High TIME_WAIT can indicate port exhaustion risk
Fix applications to properly close connections

Troubleshoot connection timeouts

Diagnosing timeouts involves checking connection states and using tools like nc for verification.

Code

# Test connectivity to specific host
nc -zv 203.0.113.50 443

# Check if port is accessible via netstat
netstat -an | grep 203.0.113.50

# Verify listening port with specific binding
sudo netstat -tlnp | grep ":8080"

# Check for firewall issues (look for many SYN_SENT)
netstat -an | grep SYN_SENT | head -5

# Trace connection attempt steps
sudo tcpdump -i any -n 'port 8080' &
# Then attempt connection in another terminal
# Use Ctrl+C to stop tcpdump

Execution

netstat -an | grep SYN_SENT | wc -l

Output

SYN_SENT indicates connection attempt
Many SYN_SENT from one source suggests blocked port
Check firewall rules with iptables or firewall-cmd
Use tcpdump for packet-level debugging

Count Connections by State

Analyze connection distribution and statistics

Count connections by state

Aggregating connections by state provides overview of network health and connection patterns.

Code

# Show count of each connection state
netstat -an | tail -n +3 | awk '{print $NF}' | sort | uniq -c | sort -rn

# Show only unique states and their counts
netstat -an | grep -o -E "LISTEN|ESTABLISHED|TIME_WAIT|CLOSE_WAIT" | sort | uniq -c

# Count established connections
netstat -an | grep ESTABLISHED | wc -l

# Count listening sockets
netstat -an | grep LISTEN | wc -l

# Show breakdown with nice formatting
echo "Connection Statistics ($(date))"
echo "================================"
netstat -an | tail -n +3 | awk '{s[$NF]++} END {for (state in s) print state, s[state]}' | sort -k2 -rn

Execution

netstat -an 2>/dev/null | tail -n +3 | awk '{s[$NF]++} END {for (state in s) print state, s[state]}' | sort -k2 -rn

Output

LISTEN 5
ESTABLISHED 3
TIME_WAIT 8

High LISTEN count is normal
High ESTABLISHED indicates heavy usage
High TIME_WAIT is normal cleanup
Any CLOSE_WAIT indicates application issues

Generate connection reports

Comprehensive reporting provides visibility into network usage and health metrics.

Code

# Generate connection report
#!/bin/bash
echo "Network Connection Report - $(date)"
echo "======================================"
echo ""
echo "Total connections:"
netstat -an | tail -n +3 | wc -l
echo ""
echo "Connections by state:"
netstat -an | tail -n +3 | awk '{s[$NF]++} END {for (state in s) printf "  %-15s %d\n", state, s[state]}' | sort -k2 -rn
echo ""
echo "Top ports in use:"
netstat -an | tail -n +3 | awk '{print $4}' | cut -d: -f2 | sort | uniq -c | sort -rn | head -5
echo ""
echo "Connection by protocol:"
netstat -an | tail -n +3 | awk '{print $1}' | sort | uniq -c

# Simpler version
netstat -an | tail -n +3 | awk '{print $1}' | sort | uniq -c

Execution

netstat -an | tail -n +3 | awk '{print $1}' | sort | uniq -c

Output

5 tcp
2 tcp6
3 udp

Useful for documentation and audits
Can be scheduled via cron for regular reports
Export to files for archival
Share with team or stakeholders

Check for Zombie Connections

Identify and clean up orphaned or zombie connections

Detect zombie and orphaned connections

Zombie/orphaned connections accumulate when applications don't properly close sockets.

Code

# Show CLOSE_WAIT connections (possible zombies)
netstat -an | grep CLOSE_WAIT | wc -l

# Show LAST_ACK connections (connection cleanup)
netstat -an | grep LAST_ACK | wc -l

# Show all non-standard connection states
netstat -an | grep -v -E "LISTEN|ESTABLISHED|^Proto|^Active"

# Identify which application has most CLOSE_WAIT
sudo netstat -anp | grep CLOSE_WAIT | awk '{print $NF}' | cut -d/ -f2 | sort | uniq -c | sort -rn

# Monitor CLOSE_WAIT trend
for i in {1..5}; do
  echo "Check $i: $(netstat -an | grep CLOSE_WAIT | wc -l) CLOSE_WAIT connections"
  sleep 10
done

Execution

netstat -an 2>/dev/null | grep CLOSE_WAIT | wc -l

Output

CLOSE_WAIT indicates application bug
Not system issue - application must close properly
TIME_WAIT is normal and automatic
Monitor trends to identify problem apps

Clean up zombie connections

Cleaning up zombie connections requires fixing the application code or restarting the service.

Code

# Show process with CLOSE_WAIT connections
sudo netstat -anp | grep CLOSE_WAIT

# Restart problematic application (best approach)
# sudo systemctl restart service-name

# Force close connections if necessary (not recommended)
# This forces the process to drop connections
# sudo kill -9 <PID>

# Monitor after restart
watch -n 5 'sudo netstat -anp | grep CLOSE_WAIT | wc -l'

# Create alert script
CLOSE_WAIT=$(netstat -an | grep CLOSE_WAIT | wc -l)
if [ $CLOSE_WAIT -gt 50 ]; then
  echo "Alert: $CLOSE_WAIT CLOSE_WAIT connections detected"
  # Send alert, restart app, etc
fi

Execution

sudo netstat -anp 2>/dev/null | grep CLOSE_WAIT | wc -l

Output

Restarting application is preferred solution
Killing process is last resort
Fix application code to proper close sockets
Implement connection pooling and cleanup

Netstat

Getting Started

What is Netstat

Accessibility

Keywords

Install and verify netstat installation

Netstat overview and capabilities

Core Concepts

Accessibility

Keywords

Understand netstat output columns and fields

Understand connection states and transmission protocol

Modern Alternatives

Accessibility

Best Practices

Common Errors

Keywords

Use ss command instead of netstat

Compare netstat and ss output

Basic Usage

Show All Connections

Accessibility

Keywords

Display all network connections

Show connections with detailed information

List Listening Ports

Accessibility

Keywords

Show all listening ports and services

Find specific listening services

Protocol-Specific Display

Accessibility

Best Practices

Common Errors

Keywords

Display TCP and UDP connections separately

Show both IPv4 and IPv6 connections

Finding Connections and Ports

Find Listening Port

Accessibility

Keywords

Find process listening on specific port

Find all connections from specific IP

Connections by Process

Accessibility

Keywords

Show connections for specific process

Analyze connection statistics by process

Established Connections

Accessibility

Best Practices

Common Errors

Keywords

Show only established connections

Monitor active connections with details

Connection States

TCP States Explained

Accessibility

Keywords

Understand TCP connection states

Show connections in specific states

Timeout and Waiting States

Accessibility

Keywords

Monitor TIME_WAIT connections

Identify and analyze CLOSE_WAIT connections

Connection Flow Analysis

Accessibility

Best Practices

Common Errors

Keywords

Analyze connection flow states

Detect and diagnose connection issues

Network Statistics and Analysis

Network Statistics

Accessibility

Keywords

Display protocol statistics

Analyze connection and packet statistics

Routing Table
