Kubernetes

Getting Started

Core Kubernetes concepts and initial setup for beginners

Kubernetes Basics

Introduction to Kubernetes architecture and core concepts

Understand Kubernetes architecture

Shows your Kubernetes cluster endpoints and components

Code

# Kubernetes architecture consists of:
# 1. Control Plane (Master): Manages cluster state and decisions
# 2. Worker Nodes: Run containerized applications
# 3. Pods: Smallest deployable units (wrappers around containers)
# 4. Services: Expose pods to network traffic
# 5. Storage: Persistent data storage for pods

# Analogy to VMs:
# Traditional: Cluster -> Node -> VM -> Application
# Kubernetes: Cluster -> Node -> Pod -> Container

# Key resources:
# - Pod: Single or multiple containers sharing network
# - Deployment: Manages pod replicas
# - Service: Network access to pods
# - ConfigMap: Configuration data
# - PersistentVolume: Storage resources

Execution

kubectl cluster-info

Output

Kubernetes control plane is running at https://127.0.0.1:6443
CoreDNS is running at https://127.0.0.1:6443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

Requires kubectl and KUBECONFIG configured
Control plane manages cluster operations
Worker nodes run actual workloads

Check cluster nodes and capacity

Lists all nodes in your cluster with their status and information

Code

# Get list of all nodes in cluster
kubectl get nodes

# Get detailed node information
kubectl get nodes -o wide

# View node resource capacities and allocations
kubectl top nodes

# Describe specific node
kubectl describe node node-1

Execution

kubectl get nodes -o wide

Output

NAME       STATUS   ROLES    AGE   VERSION   INTERNAL-IP   EXTERNAL-IP
minikube   Ready    master   10d   v1.24.0   192.168.1.1   <none>

STATUS Ready means node is healthy and accepting workloads
Roles indicate control plane vs worker nodes
top requires metrics-server to be installed

Verify kubectl installation and context

Verifies kubectl installation and shows active cluster context

Code

# Check kubectl version
kubectl version --client

# View current context
kubectl config current-context

# List all available contexts
kubectl config get-contexts

# Switch to different context
kubectl config use-context docker-desktop

# Get cluster information
kubectl config view

Execution

kubectl version --client

Output

Client Version: v1.26.0
Kustomize Version: v4.5.4

Context determines which cluster kubectl connects to
KUBECONFIG can contain multiple clusters
Switch contexts for multi-cluster environments

Install and Configure kubectl

Set up kubectl CLI tool and configure cluster access

Install kubectl on Linux

Installs kubectl CLI tool required for managing Kubernetes clusters

Code

# Download kubectl binary
curl -LO "https://dl.k8s.io/release/$(curl -L -s https://dl.k8s.io/release/stable.txt)/bin/linux/amd64/kubectl"

# Make it executable
chmod +x kubectl

# Move to PATH
sudo mv kubectl /usr/local/bin/

# Verify installation
kubectl version --client

# Using package manager (Ubuntu/Debian)
sudo apt-get update
sudo apt-get install -y kubectl

Execution

kubectl version --client

Output

Client Version: v1.26.0
Kustomize Version: v4.5.4

Always download from official Kubernetes release repository
Version should be within 1 minor version of cluster API

Configure kubectl with cloud clusters

Configures kubectl to access cloud-managed Kubernetes clusters

Code

# AWS EKS - Get cluster config
aws eks update-kubeconfig --region us-east-1 --name my-cluster

# Google GKE - Get cluster credentials
gcloud container clusters get-credentials my-cluster --zone us-central1-a

# Azure AKS - Get cluster credentials
az aks get-credentials --resource-group myResourceGroup --name myAKSCluster

# Verify kubectl can access cluster
kubectl cluster-info

Execution

kubectl config view

Output

apiVersion: v1
clusters:
- cluster:
    server: https://example.com
  name: my-cluster
contexts:
- context:
    cluster: my-cluster
    user: my-user
  name: my-context

Each cloud provider has specific commands for credential setup
Kubeconfig stored in ~/.kube/config by default

Set up kubectl shell completion

Enables tab completion for kubectl commands in your shell

Code

# Bash completion
echo "source <(kubectl completion bash)" >> ~/.bashrc
source ~/.bashrc

# Zsh completion
echo "source <(kubectl completion zsh)" >> ~/.zshrc
source ~/.zshrc

# Fish completion
kubectl completion fish | source

# Temporary completion (current session)
source <(kubectl completion bash)

Execution

kubectl completion bash

Output

# bash completion for kubectl
_kubectl_complete() { ... }

Greatly improves command line productivity
Available for bash, zsh, fish, and powershell

Namespaces and Basic Navigation

Organize resources using namespaces and navigate clusters

Explore and create namespaces

Lists and creates Kubernetes namespaces for resource organization

Code

# List all namespaces
kubectl get namespaces

# Create new namespace
kubectl create namespace development

# Create namespace with YAML
kubectl apply -f - <<EOF
apiVersion: v1
kind: Namespace
metadata:
  name: production
EOF

# Get default namespaces
# default - for user workloads
# kube-system - for system components
# kube-public - world-readable resources
# kube-node-lease - node heartbeats

Execution

kubectl get ns

Output

NAME              STATUS   AGE
default           Active   10d
kube-system       Active   10d
kube-public       Active   10d
kube-node-lease   Active   10d

Default namespace is used if not specified
Namespaces isolate resources within same cluster
Good for multi-team or multi-environment setups

Set default namespace and switch between them

Sets default namespace for kubectl commands without -n flag

Code

# Set permanent default namespace
kubectl config set-context --current --namespace=development

# View current namespace
kubectl config view --minify --output=jsonpath='{..namespace}'

# View resources in specific namespace
kubectl get pods --namespace=production
kubectl get pods -n production  # short form

# Switch context with different namespace
kubectl config use-context dev-context

Execution

kubectl config set-context --current --namespace=default

Output

Context "minikube" modified.

Default context is stored in ~/.kube/config
-n flag overrides default namespace per command

View all resources across namespaces

Lists resources across all namespaces for cluster-wide visibility

Code

# List pods across all namespaces
kubectl get pods --all-namespaces
kubectl get pods -A  # short form

# View services across all namespaces
kubectl get svc -A

# Get all resources in all namespaces
kubectl get all -A

# Describe resource in specific namespace
kubectl describe pod my-pod -n production

Execution

kubectl get pods -A

Output

NAMESPACE     NAME                             READY   STATUS    RESTARTS
default       nginx-pod                        1/1     Running   0
kube-system   coredns-64897fb6d9-x8z5k         1/1     Running   0
production    app-deployment-abc123-xyz789     1/1     Running   1

-A flag is equivalent to --all-namespaces
Useful for troubleshooting across entire cluster

Cluster Management

Manage cluster configuration, nodes, resources, and monitoring

Cluster Context and Configuration

Manage multiple clusters and kubeconfig contexts

Manage kubeconfig contexts and clusters

Shows all available contexts and allows switching between clusters

Code

# View all contexts and clusters
kubectl config get-contexts
kubectl config get-clusters

# Get current context
kubectl config current-context

# Switch to different context
kubectl config use-context another-cluster

# Create new context
kubectl config set-context production --cluster=prod-cluster --user=prod-user

# Delete context
kubectl config delete-context old-context

Execution

kubectl config get-contexts

Output

CURRENT   NAME              CLUSTER         AUTHINFO        NAMESPACE
*         minikube          minikube        minikube        default
          docker-desktop    docker-desktop  docker-desktop  default
          kind-cluster1     kind-cluster1   kind-cluster1   default

Context combines cluster, user, and namespace information
* indicates current context

Configure cluster authentication

Manually configure cluster, user, and context settings

Code

# Set cluster details
kubectl config set-cluster my-cluster \
  --server=https://kubernetes.example.com:6443 \
  --certificate-authority=/path/to/ca.crt

# Set user authentication
kubectl config set-credentials my-user \
  --client-certificate=/path/to/client.crt \
  --client-key=/path/to/client.key

# Create context binding user to cluster
kubectl config set-context my-context \
  --cluster=my-cluster \
  --user=my-user \
  --namespace=default

# Verify configuration
kubectl config view

Execution

kubectl config view

Output

apiVersion: v1
clusters:
- cluster:
    server: https://kubernetes.example.com:6443
users:
- name: my-user
contexts:
- context:
    cluster: my-cluster
    user: my-user

Certificates can be base64-encoded in kubeconfig
kubectl config view shows merged configuration

Merge kubeconfig files and manage credentials

Manage multiple kubeconfig files for different clusters

Code

# View kubeconfig location
echo $KUBECONFIG

# Merge multiple kubeconfig files
export KUBECONFIG=~/.kube/config:~/.kube/prod-config:/tmp/temp-config
kubectl config view --merge

# Flatten kubeconfig (consolidate into single file)
kubectl config view --flatten > ~/.kube/consolidated-config

# Set KUBECONFIG permanently
echo "export KUBECONFIG=$HOME/.kube/config" >> ~/.bashrc

# Verify current kubeconfig
kubectl config view --minify

Execution

echo $KUBECONFIG

Output

/home/user/.kube/config

Multiple KUBECONFIG files are separated by colon (:)
Useful for managing dev, staging, and production clusters

Cluster Information and Monitoring

Monitor cluster health, resources, and component status

Check cluster health and component status

Shows running components and their endpoints

Code

# Get cluster information
kubectl cluster-info

# Get system components (requires metrics-server)
kubectl get componentstatuses

# Check API server and cluster version
kubectl api-versions

# List all API resources available
kubectl api-resources

# View cluster details
kubectl describe cluster

Execution

kubectl cluster-info

Output

Kubernetes control plane is running at https://127.0.0.1:6443
CoreDNS is running at https://127.0.0.1:6443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

Critical for verifying cluster connectivity
Dump shows more detailed debug information

Monitor node resources and health

Shows CPU and memory usage for all cluster nodes

Code

# List nodes with resource information
kubectl get nodes --show-labels

# Get node resource usage
kubectl top nodes

# Describe specific node for details
kubectl describe node minikube

# Check node logs (requires SSH or specific monitoring)
kubectl logs -f -n kube-system --tail=50 <pod-name>

# Get node conditions
kubectl get nodes -o jsonpath='{.items[*].status.conditions}' | jq .

Execution

kubectl top nodes

Output

NAME       CPU(cores)   CPU%   MEMORY(Mi)   MEMORY%
minikube   245m         12%    1234Mi       32%

Requires metrics-server installed for top command
CPU in millicores, memory in megabytes

Check persistent volume and storage status

Lists persistent storage resources in the cluster

Code

# List persistent volumes
kubectl get pv

# List persistent volume claims
kubectl get pvc --all-namespaces

# Check storage classes
kubectl get storageclass

# Describe specific PV
kubectl describe pv pv-name

# Check PVC status
kubectl describe pvc pvc-name -n namespace

Execution

kubectl get pv

Output

NAME       CAPACITY   ACCESS MODES   RECLAIM   STATUS   CLAIM
pv-001     10Gi       RWO            Delete    Bound    ns/pvc-001

PV is cluster-level, PVC is namespace-level
Status should be Bound for normal operation

Node and Resource Management

Manage cluster nodes, taints, and resource quotas

Cordon and drain nodes for maintenance

Safely cordons and drains nodes for maintenance

Code

# Cordon node (prevent new pods from scheduling)
kubectl cordon node-1

# Drain node (evict all pods safely)
kubectl drain node-1 --ignore-daemonsets --delete-emptydir-data

# Uncordon node (allow scheduling again)
kubectl uncordon node-1

# Check node status
kubectl get nodes
kubectl describe node node-1

Execution

kubectl get nodes

Output

NAME       STATUS                     ROLES   AGE
node-1     Ready,SchedulingDisabled   <none>  10d
node-2     Ready                      <none>  10d

SchedulingDisabled status indicates cordoned node
Drain ensures graceful pod termination

Add and remove node taints

Adds and removes taints to control pod scheduling

Code

# Add taint to node (prevents scheduling unless tolerated)
kubectl taint nodes node-1 key=value:NoSchedule

# Add effect types:
# NoSchedule - new pods won't be scheduled
# NoExecute - existing pods will be evicted
# PreferNoSchedule - prefer not to schedule but may

# Remove taint from node
kubectl taint nodes node-1 key=value:NoSchedule-

# View node taints
kubectl describe node node-1 | grep Taints

Execution

kubectl describe node node-1 | grep Taints

Output

Taints: gpu=true:NoSchedule

Pods need matching tolerations to schedule on tainted nodes
Common for GPU nodes or specialized hardware

Set resource quotas and limits per namespace

Sets resource limits for namespaces to prevent overallocation

Code

# Create resource quota for namespace
kubectl create quota myrquota --hard=pods=10,cpu=3,memory=10Gi -n development

# View resource quotas
kubectl get resourcequota -n development

# Describe quota details
kubectl describe resourcequota myrquota -n development

# Create with YAML for more control
kubectl apply -f - <<EOF
apiVersion: v1
kind: ResourceQuota
metadata:
  name: compute-quota
  namespace: development
spec:
  hard:
    requests.cpu: "10"
    requests.memory: "20Gi"
    limits.cpu: "20"
    limits.memory: "40Gi"
EOF

Execution

kubectl get resourcequota -A

Output

NAMESPACE    NAME         AGE   REQUEST.CPU   REQUESTMEMORY
development  myrquota     5d    500m / 3      2Gi / 10Gi

Quotas prevent namespace from consuming excessive cluster resources
Pods larger than quota cannot be created

Pod Management

Create, manage, inspect, and debug Kubernetes pods

Creating and Listing Pods

Create pods imperatively and declaratively, list and filter them

Create pods imperatively with kubectl run

Creates pods using imperative kubectl run command

Code

# Create simple pod from image
kubectl run nginx-pod --image=nginx

# Create pod with port mapping
kubectl run web --image=nginx --port=8080

# Create pod with resource requests/limits
kubectl run app --image=myapp --requests=cpu=100m,memory=128Mi --limits=cpu=500m,memory=512Mi

# Create pod with command
kubectl run busybox --image=busybox --command -- sleep 3600

# Create pod in specific namespace
kubectl run test-pod --image=alpine -n development

# Create pod and output YAML (dry-run)
kubectl run nginx-pod --image=nginx --dry-run=client -o yaml

Execution

kubectl run test-pod --image=alpine --dry-run=client -o yaml

Output

apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  name: test-pod
spec:
  containers:
  - image: alpine
    name: test-pod

Imperative approach is fast for quick testing
Use dry-run to preview YAML before creating

Create pods declaratively with YAML manifests

Creates pods using declarative YAML manifests

Code

# Create pod from YAML file
kubectl apply -f pod.yaml

# Create pod from inline YAML
kubectl apply -f - <<EOF
apiVersion: v1
kind: Pod
metadata:
  name: web-pod
  namespace: default
  labels:
    app: web
spec:
  containers:
  - name: nginx
    image: nginx:latest
    ports:
    - containerPort: 80
    resources:
      requests:
        cpu: 100m
        memory: 128Mi
      limits:
        cpu: 500m
        memory: 512Mi
  - name: sidecar
    image: busybox
    command: ['sleep', '3600']
EOF

# Verify pod creation
kubectl get pods

Execution

kubectl get pods

Output

NAME      READY   STATUS    RESTARTS   AGE
web-pod   2/2     Running   0          2m

Declarative approach is preferred for reproducibility
YAML files can be version controlled
Multiple containers can run in same pod

List and filter pods

Lists pods with various filtering and output options

Code

# List pods in current namespace
kubectl get pods

# List pods with detailed info
kubectl get pods -o wide

# List pods across all namespaces
kubectl get pods -A

# List pods with labels
kubectl get pods --show-labels

# Filter pods by label
kubectl get pods -l app=web

# Filter by multiple labels
kubectl get pods -l app=web,tier=frontend

# List pods with custom columns
kubectl get pods -o custom-columns=NAME:metadata.name,STATUS:status.phase,IP:status.podIP

Execution

kubectl get pods -o wide

Output

NAME      STATUS   IP           NODE      NOMINATED
web-pod   Running  10.244.0.5   minikube  <none>

Default shows only current namespace
-o flag controls output format (json, yaml, custom-columns)

Inspecting and Debugging Pods

Describe, view logs, and debug pod issues

Describe pods and view details

Shows detailed pod information including events and status

Code

# Get basic information about pod
kubectl get pod web-pod

# Get detailed pod information
kubectl describe pod web-pod

# View pod definition in YAML
kubectl get pod web-pod -o yaml

# View pod in JSON format
kubectl get pod web-pod -o json

# Extract specific fields with JSONPath
kubectl get pod web-pod -o jsonpath='{.status.phase}'
kubectl get pod web-pod -o jsonpath='{.spec.containers[0].image}'

Execution

kubectl describe pod web-pod

Output

Name:         web-pod
Namespace:    default
Status:       Running
IP:           10.244.0.5
Containers:
  nginx:
    Image: nginx:latest
  State: Running

describe shows useful events and error messages
Events help identify why pods fail to start

View pod logs and stream output

Shows container logs for debugging application issues

Code

# View logs from pod
kubectl logs web-pod

# View logs from specific container in multi-container pod
kubectl logs web-pod -c nginx

# Stream logs in real-time
kubectl logs -f web-pod

# View logs from previous container (crashed pods)
kubectl logs web-pod --previous

# Show logs with timestamps
kubectl logs web-pod --timestamps=true

# Tail last 50 lines
kubectl logs web-pod --tail=50

# View logs from deployment pods
kubectl logs -l app=web --max-log-requests=10

Execution

kubectl logs web-pod --tail=20

Output

192.168.1.1 - - [28/Feb/2025:10:30:00] "GET / HTTP/1.1" 200 612
192.168.1.2 - - [28/Feb/2025:10:30:01] "GET /index.html HTTP/1.1" 200 612

-f flag tails logs in real-time like tail -f
--previous shows logs from before container restart

Interactive debugging and shell access

Executes commands and provides shell access to running pods

Code

# Execute command in running pod
kubectl exec web-pod -- ls -la

# Get interactive shell in pod
kubectl exec -it web-pod -- /bin/bash
kubectl exec -it web-pod -- /bin/sh

# Execute command in specific container
kubectl exec -it web-pod -c nginx -- /bin/bash

# Run debugging sidecar in pod
kubectl debug web-pod -it --image=busybox

# Copy files from pod
kubectl cp web-pod:/var/www/html/index.html ./index.html
# Copy files to pod
kubectl cp ./config.yaml web-pod:/etc/config.yaml

Execution

kubectl exec -it web-pod -- hostname

Output

web-pod

-i flag keeps stdin open, -t allocates tty
Useful for runtime troubleshooting and inspection

Deleting and Cleaning Up Pods

Delete pods and manage pod lifecycle

Delete single and multiple pods

Deletes pods from the cluster

Code

# Delete single pod
kubectl delete pod web-pod

# Delete multiple pods by name
kubectl delete pod web-pod app-pod db-pod

# Delete all pods in namespace
kubectl delete pods --all

# Delete all pods in all namespaces
kubectl delete pods -A --all

# Delete with confirmation
kubectl delete pod web-pod  # will prompt for confirmation

Execution

kubectl delete pod web-pod

Output

pod "web-pod" deleted

Delete operations are immediate (use graceful termination)
Bare pods are not recreated; use Deployments for self-healing

Graceful pod termination and force delete

Gracefully terminates pods with shutdown timeout

Code

# Delete with grace period (seconds to shutdown cleanly)
kubectl delete pod web-pod --grace-period=30

# Force delete immediately (no grace period)
kubectl delete pod web-pod --grace-period=0 --force

# Delete using label selector
kubectl delete pods -l app=web

# Delete using field selector
kubectl delete pods --field-selector=status.phase=Failed

# Check termination status during deletion
kubectl get pod web-pod --watch

Execution

kubectl delete pod web-pod --grace-period=10

Output

pod "web-pod" deleted

Default grace period is 30 seconds
Pod has time to close connections and save state

Deployment Management

Deploy applications, manage replicas, and perform rolling updates

Creating Deployments

Create deployments imperatively and declaratively

Create deployments imperatively

Creates deployments using imperative kubectl commands

Code

# Create deployment from image
kubectl create deployment web --image=nginx

# Create deployment with replicas
kubectl create deployment web --image=nginx --replicas=3

# Create deployment and save YAML
kubectl create deployment web --image=nginx --dry-run=client -o yaml > web-deployment.yaml

# Create deployment with port
kubectl run web --image=nginx --port=80 --replicas=3

# Verify deployment creation
kubectl get deployments
kubectl get pods

Execution

kubectl create deployment web --image=nginx --replicas=3

Output

deployment.apps/web created

create is imperative, while apply is declarative
Deployments automatically create ReplicaSet

Create deployments with YAML manifests

Creates deployments declaratively with full control

Code

# Create deployment from YAML
kubectl apply -f - <<EOF
apiVersion: apps/v1
kind: Deployment
metadata:
  name: web-deployment
  labels:
    app: web
spec:
  replicas: 3
  selector:
    matchLabels:
      app: web
  template:
    metadata:
      labels:
        app: web
    spec:
      containers:
      - name: nginx
        image: nginx:1.21
        ports:
        - containerPort: 80
        resources:
          requests:
            cpu: 100m
            memory: 128Mi
          limits:
            cpu: 500m
            memory: 512Mi
        livenessProbe:
          httpGet:
            path: /
            port: 80
          initialDelaySeconds: 30
          periodSeconds: 10
EOF

# List deployments
kubectl get deployments

Execution

kubectl get deployments -o wide

Output

NAME             READY   UP-TO-DATE   AVAILABLE   AGE
web-deployment   3/3     3            3           2m

YAML approach is reproducible and version-controllable
spec.replicas defines number of pod replicas
selector must match template labels

Create deployments with health checks

Creates deployments with health checks for better reliability

Code

# Create deployment with liveness and readiness probes
kubectl apply -f - <<EOF
apiVersion: apps/v1
kind: Deployment
metadata:
  name: app-deployment
spec:
  replicas: 2
  selector:
    matchLabels:
      app: app
  template:
    metadata:
      labels:
        app: app
    spec:
      containers:
      - name: app
        image: myapp:v1
        ports:
        - containerPort: 8080
        livenessProbe:
          httpGet:
            path: /health
            port: 8080
          initialDelaySeconds: 10
          periodSeconds: 10
        readinessProbe:
          httpGet:
            path: /ready
            port: 8080
          initialDelaySeconds: 5
          periodSeconds: 5
EOF

Execution

kubectl describe deployment app-deployment

Output

Name:                   app-deployment
Replicas:               2 desired | 2 updated | 2 ready
Strategy:               RollingUpdate

Liveness probe restarts unhealthy containers
Readiness probe controls traffic to pods

Scaling Deployments

Scale deployments up and down dynamically

Manually scale deployments

Scales deployments manually by changing replica count

Code

# Get deployment info
kubectl get deployments

# Scale deployment to 5 replicas
kubectl scale deployment web-deployment --replicas=5

# Scale multiple deployments
kubectl scale deployment web-deployment app-deployment --replicas=3

# Verify scaling
kubectl get deployments
kubectl get pods

# Scale down to 0 (stop deployment)
kubectl scale deployment web-deployment --replicas=0

Execution

kubectl scale deployment web-deployment --replicas=5

Output

deployment.apps/web-deployment scaled

Scaling is immediate
Previous pods will be terminated gracefully

Set up horizontal pod autoscaling

Sets up automatic scaling based on metrics

Code

# Create HPA imperatively
kubectl autoscale deployment web-deployment --min=1 --max=10 --cpu-percent=80

# View HPA status
kubectl get hpa

# Describe HPA details
kubectl describe hpa web-deployment

# Create HPA with YAML for more control
kubectl apply -f - <<EOF
apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: web-hpa
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: web-deployment
  minReplicas: 2
  maxReplicas: 10
  metrics:
  - type: Resource
    resource:
      name: cpu
      target:
        type: Utilization
        averageUtilization: 80
EOF

Execution

kubectl get hpa

Output

NAME          REFERENCE                  TARGETS   MINPODS  MAXPODS
web-hpa       Deployment/web-deployment  45%/80%   2        10

Requires metrics-server for CPU/memory metrics
HPA v2 supports custom metrics

Monitor scaling events and history

Monitors horizontal pod autoscaling events

Code

# Monitor scaling in real-time
kubectl get hpa --watch

# Check HPA events
kubectl describe hpa web-hpa

# View scaling history
kubectl get events --field-selector involvedObject.name=web-deployment

# Check deployment history
kubectl rollout history deployment web-deployment

Execution

kubectl get hpa --watch

Output

NAME      REFERENCE             TARGETS   MINPODS  MAXPODS  REPLICAS  AGE
web-hpa   Deployment/web-deploy 88%/80%   2        10       8         3m

HPA cooldown prevents rapid scaling churn
Monitor targets to verify autoscaling behavior

Updating and Rolling Back Deployments

Update application versions and manage rollouts

Update deployment images

Updates deployment image to new version

Code

# Update image in deployment
kubectl set image deployment/web-deployment nginx=nginx:1.22

# Update multiple containers
kubectl set image deployment/app app=myapp:v2 sidecar=sidecar:v1 --record

# Update from file
kubectl apply -f - <<EOF
apiVersion: apps/v1
kind: Deployment
metadata:
  name: web-deployment
spec:
  template:
    spec:
      containers:
      - name: nginx
        image: nginx:1.22
EOF

# Watch rollout progress
kubectl rollout status deployment/web-deployment

Execution

kubectl set image deployment/web-deployment nginx=nginx:1.22

Output

deployment.apps/web-deployment image updated

Triggers rolling update by default
Old pods are gradually replaced with new version

Perform rolling updates and monitor progress

Monitors and controls rolling update process

Code

# Apply updated deployment
kubectl apply -f web-deployment.yaml

# Watch rollout status
kubectl rollout status deployment/web-deployment

# Check rollout history
kubectl rollout history deployment/web-deployment

# View specific revision details
kubectl rollout history deployment/web-deployment --revision=2

# Pause rollout if issues detected
kubectl rollout pause deployment/web-deployment

# Resume paused rollout
kubectl rollout resume deployment/web-deployment

Execution

kubectl rollout status deployment/web-deployment

Output

deployment "web-deployment" successfully rolled out

Pause allows verification before continuing update
History shows all previous revisions

Rollback deployments to previous versions

Reverts deployment to previous working version

Code

# Rollback to previous revision
kubectl rollout undo deployment/web-deployment

# Rollback to specific revision
kubectl rollout undo deployment/web-deployment --to-revision=2

# Check rollback status
kubectl rollout status deployment/web-deployment

# Verify rollback with describe
kubectl describe deployment web-deployment

# Check pod images to confirm rollback
kubectl get pods -o wide

Execution

kubectl rollout undo deployment/web-deployment

Output

deployment.apps/web-deployment rolled back

Undo creates new ReplicaSet with old version
Useful for quick recovery from bad deployments

Service & Ingress

Expose applications with Services and Ingress

Creating Services

Expose pods with ClusterIP, NodePort, and LoadBalancer services

Create services imperatively

Creates services to expose deployments within or outside cluster

Code

# Expose deployment as ClusterIP service
kubectl expose deployment web-deployment --type=ClusterIP --port=80

# Expose as NodePort service
kubectl expose deployment web-deployment --type=NodePort --port=80 --target-port=8080

# Expose as LoadBalancer service
kubectl expose deployment web-deployment --type=LoadBalancer --port=80

# List created services
kubectl get svc

# Get service details
kubectl describe svc web-deployment

Execution

kubectl expose deployment web-deployment --type=ClusterIP --port=80

Output

service/web-deployment exposed

ClusterIP: internal only
NodePort: accessible on node IP
LoadBalancer: managed external IP

Create services with YAML

Creates services declaratively with full control

Code

# Create ClusterIP service
kubectl apply -f - <<EOF
apiVersion: v1
kind: Service
metadata:
  name: web-service
spec:
  type: ClusterIP
  selector:
    app: web
  ports:
  - port: 80
    targetPort: 8080
    protocol: TCP
EOF

# Create NodePort service
kubectl apply -f - <<EOF
apiVersion: v1
kind: Service
metadata:
  name: web-nodeport
spec:
  type: NodePort
  selector:
    app: web
  ports:
  - port: 80
    targetPort: 8080
    nodePort: 30080
EOF

# Create LoadBalancer service
kubectl apply -f - <<EOF
apiVersion: v1
kind: Service
metadata:
  name: web-lb
spec:
  type: LoadBalancer
  selector:
    app: web
  ports:
  - port: 80
    targetPort: 8080
EOF

Execution

kubectl get svc

Output

NAME          TYPE        CLUSTER-IP  PORT(S)
web-service   ClusterIP   10.0.0.1    80/TCP

selector determines which pods receive traffic
targetPort is container port, port is service port

List and inspect services

Lists services and their endpoints

Code

# List services
kubectl get svc

# List in all namespaces
kubectl get svc -A

# Get service endpoints
kubectl get endpoints

# Describe service details
kubectl describe svc web-service

# Get service YAML
kubectl get svc web-service -o yaml

# Watch for external IP (LoadBalancer)
kubectl get svc -w

Execution

kubectl get svc -o wide

Output

NAME          TYPE       SELECTOR   IP         EXTERNAL-IP
web-service   ClusterIP  app=web    10.0.0.1   <none>

Endpoints show which pods the service routes to
EXTERNAL-IP may take time for LoadBalancer type

Setting up Ingress

Configure Ingress for HTTP/HTTPS routing

Create basic Ingress routes

Creates basic Ingress for routing HTTP traffic

Code

# Create simple path-based Ingress
kubectl apply -f - <<EOF
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: web-ingress
spec:
  rules:
  - http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: web-service
            port:
              number: 80
EOF

# List ingresses
kubectl get ingress

# Get Ingress IP address
kubectl get ingress -o wide

Execution

kubectl get ingress

Output

NAME          CLASS   HOSTS   ADDRESS       PORTS
web-ingress   nginx   *       192.168.1.1   80

Requires Ingress Controller (nginx, traefik, etc.)
Address is Ingress Controller's IP

Configure hostname-based routing

Routes different hosts to different services

Code

# Create host-based Ingress
kubectl apply -f - <<EOF
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: web-ingress
spec:
  rules:
  - host: example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: web-service
            port:
              number: 80
  - host: api.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: api-service
            port:
              number: 8080
EOF

Execution

kubectl describe ingress web-ingress

Output

Name:             web-ingress
Rules:
  Host            Path Backends
  example.com     /    web-service:80
  api.example.com /    api-service:8080

Requires DNS pointing to Ingress IP
Multiple rules for VHOST configuration

Configure TLS termination with Ingress

Configures HTTPS/TLS termination for Ingress

Code

# Create TLS secret
kubectl create secret tls web-tls --cert=cert.pem --key=key.pem

# Create Ingress with TLS
kubectl apply -f - <<EOF
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: web-ingress-tls
spec:
  tls:
  - hosts:
    - example.com
      secretName: web-tls
  rules:
  - host: example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: web-service
            port:
              number: 80
EOF

# Verify TLS setup
kubectl describe ingress web-ingress-tls

Execution

kubectl get secrets

Output

NAME       TYPE                DATA   AGE
web-tls    kubernetes.io/tls   2      3m

TLS certificate stored as Secret
Ingress Controller terminates SSL

Port Forwarding and Debugging

Forward local ports to cluster resources for debugging

Forward local port to pod

Creates local port forward to pod

Code

# Forward local to pod
kubectl port-forward pod/web-pod 8000:80

# Forward with background process
kubectl port-forward pod/web-pod 8000:80 &

# Forward to specific pod in deployment
kubectl port-forward deployment/web-deployment 8000:80

# Forward with address binding
kubectl port-forward pod/web-pod 127.0.0.1:8000:80

# Forward random local port
kubectl port-forward pod/web-pod :80

Execution

kubectl port-forward pod/web-pod 8000:80 &

Output

Forwarding from 127.0.0.1:8000 -> 80
Forwarding from [::1]:8000 -> 80

Access pod at localhost:8000 from host
Useful for testing without exposing service

Access services through port forwarding

Forwards to Service which routes to backend pods

Code

# Forward to service
kubectl port-forward service/web-service 8000:80

# Forward to service in specific namespace
kubectl port-forward -n production service/db-service 5432:5432

# Forward multiple ports
kubectl port-forward pod/app 8000:8000 8080:8080

# Kill port forward
# Use Ctrl+C or kill process
ps aux | grep port-forward
kill <pid>

Execution

kubectl port-forward service/web-service 8000:80

Output

Forwarding from 127.0.0.1:8000 -> 80

Service provides load balancing across pods
Random pod is selected if multiple exist

Storage Management

Manage persistent storage with volumes and storage classes

Persistent Volumes and Claims

Create and manage persistent storage

Create persistent volumes and claims

Creates persistent storage volumes and claims

Code

# Create Persistent Volume
kubectl apply -f - <<EOF
apiVersion: v1
kind: PersistentVolume
metadata:
  name: pv-001
spec:
  capacity:
    storage: 10Gi
  accessModes:
    - ReadWriteOnce
  persistentVolumeReclaimPolicy: Retain
  storageClassName: manual
  hostPath:
    path: /data/pv-001
EOF

# Create Persistent Volume Claim
kubectl apply -f - <<EOF
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: pvc-001
  namespace: default
spec:
  accessModes:
    - ReadWriteOnce
  storageClassName: manual
  resources:
    requests:
      storage: 5Gi
EOF

# List PVs and PVCs
kubectl get pv
kubectl get pvc

Execution

kubectl get pv,pvc

Output

NAME     CAPACITY  ACCESSMODES  STATUS   CLAIM
pv-001   10Gi      RWO          Bound    default/pvc-001

PV is cluster resource, PVC is namespace resource
Status Bound means PVC successfully claimed PV

Use volumes in pod specifications

Mounts persistent volume in pod using PVC

Code

# Create pod with PVC volume
kubectl apply -f - <<EOF
apiVersion: v1
kind: Pod
metadata:
  name: data-app
spec:
  containers:
  - name: app
    image: busybox
    command: ['sleep', '3600']
    volumeMounts:
    - name: data-volume
      mountPath: /data
  volumes:
  - name: data-volume
    persistentVolumeClaim:
      claimName: pvc-001
EOF

# Verify PVC is mounted
kubectl get pod data-app -o yaml | grep -A5 volumes

Execution

kubectl describe pod data-app | grep -A5 Mounts

Output

Mounts:
  /data from data-volume (rw)

mountPath is where volume appears in container
Volume must exist or pod will not start

Manage storage lifecycle

Manages PV/PVC lifecycle and reclamation policies

Code

# Check PVC details
kubectl describe pvc pvc-001

# View PV details
kubectl describe pv pv-001

# Delete PVC
kubectl delete pvc pvc-001

# Delete PV
kubectl delete pv pv-001

# Check reclaim policy behavior
# - Retain: Keep PV after PVC deletion
# - Delete: Remove PV after PVC deletion
# - Recycle: Clear PV data (deprecated)

Execution

kubectl describe pvc pvc-001

Output

Name:          pvc-001
Status:        Bound
Volume:        pv-001
Capacity:      5Gi

Reclaim policy determines what happens after PVC deletion
Retain preserves data for manual recovery

Storage Classes and Dynamic Provisioning

Use storage classes for dynamic volume provisioning

Create and list storage classes

Creates storage classes for automatic volume provisioning

Code

# Create storage class
kubectl apply -f - <<EOF
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: fast-storage
provisioner: kubernetes.io/aws-ebs
parameters:
  type: gp3
  iops: "3000"
  throughput: "125"
reclaimPolicy: Delete
allowVolumeExpansion: true
EOF

# List storage classes
kubectl get storageclass

# Set default storage class
kubectl patch storageclass fast-storage -p '{"metadata": {"annotations":{"storageclass.kubernetes.io/is-default-class":"true"}}}'

Execution

kubectl get storageclass

Output

NAME           PROVISIONER             RECLAIMPOLICY
fast-storage   kubernetes.io/aws-ebs   Delete

Provisioner depends on cloud provider
Parameters vary by provisioner

Use storage class in PVC

Automatically provisions PV when PVC is created

Code

# Create PVC using storage class
kubectl apply -f - <<EOF
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: app-storage
spec:
  accessModes:
    - ReadWriteOnce
  storageClassName: fast-storage
  resources:
    requests:
      storage: 50Gi
EOF

# Monitor dynamic PV creation
kubectl get pv -w

Execution

kubectl get pvc

Output

NAME          STATUS   VOLUME         CAPACITY
app-storage   Bound    pvc-abc123     50Gi

Storage class provisioner automatically creates PV
No need to manually create PV first

Expand persistent volumes

Expands PVC size without downtime

Code

# Edit PVC to increase size
kubectl patch pvc app-storage -p '{"spec":{"resources":{"requests":{"storage":"100Gi"}}}}'

# Or edit directly
kubectl edit pvc app-storage

# Monitor expansion progress
kubectl describe pvc app-storage

# Verify expansion in pod
kubectl exec -it <pod> -- df /data

Execution

kubectl describe pvc app-storage

Output

Name:          app-storage
Capacity:      100Gi

allowVolumeExpansion must be true in StorageClass
Some filesystems require filesystem expansion in pod

Volume Types and EmptyDir

Use different volume types for various scenarios

Use emptyDir and hostPath volumes

Uses emptyDir for temporary storage and hostPath for node access

Code

# Create pod with emptyDir and hostPath
kubectl apply -f - <<EOF
apiVersion: v1
kind: Pod
metadata:
  name: app-with-volumes
spec:
  containers:
  - name: app
    image: nginx
    volumeMounts:
    - name: cache
      mountPath: /cache
    - name: host-data
      mountPath: /host-data
  volumes:
  - name: cache
    emptyDir: {}
  - name: host-data
    hostPath:
      path: /data
      type: Directory
EOF

Execution

kubectl get pod app-with-volumes -o yaml

Output

volumes:
- name: cache
  emptyDir: {}

emptyDir deleted when pod terminates
hostPath accesses node filesystem

Mount ConfigMaps and Secrets as volumes

Mounts ConfigMaps and Secrets as volumes

Code

# Create ConfigMap
kubectl create configmap app-config --from-literal=key1=value1

# Create Secret
kubectl create secret generic app-secret --from-literal=password=secret

# Create pod mounting both
kubectl apply -f - <<EOF
apiVersion: v1
kind: Pod
metadata:
  name: app-with-config
spec:
  containers:
  - name: app
    image: busybox
    command: ['sleep', '3600']
    volumeMounts:
    - name: config
      mountPath: /etc/config
    - name: secret
      mountPath: /etc/secrets
  volumes:
  - name: config
    configMap:
      name: app-config
  - name: secret
    secret:
      secretName: app-secret
EOF

Execution

kubectl get configmap,secret

Output

NAME                 DATA   AGE
configmap/app-config 1      2m

ConfigMap/Secret updates appear in mounted files
Good for configuration without pod restart

Security & RBAC

Secure cluster with authentication, authorization, and policies

RBAC Roles and Bindings

Control access with Roles and RoleBindings

Create RBAC roles and bindings

Creates RBAC roles and grants permissions to service accounts

Code

# Create service account
kubectl create serviceaccount app-sa -n development

# Create role with permissions
kubectl apply -f - <<EOF
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  name: pod-reader
  namespace: development
rules:
- apiGroups: [""]
  resources: ["pods"]
  verbs: ["get", "list", "watch"]
- apiGroups: [""]
  resources: ["pods/logs"]
  verbs: ["get"]
EOF

# Create role binding
kubectl apply -f - <<EOF
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: pod-reader-binding
  namespace: development
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: Role
  name: pod-reader
subjects:
- kind: ServiceAccount
  name: app-sa
  namespace: development
EOF

# List RBAC resources
kubectl get roles,rolebindings -n development

Execution

kubectl get serviceaccounts,roles,rolebindings -n development

Output

NAME                     SECRETS   AGE
serviceaccount/app-sa    1         2m
NAME                 CREATED AT
role.rbac...pod-reader  2m

verbs define allowed actions (get, list, create, delete)
apiGroups depend on resource type (empty = core API)

Create ClusterRoles for cluster-wide permissions

Grants cluster-wide permissions across all namespaces

Code

# Create cluster role
kubectl apply -f - <<EOF
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: node-reader
rules:
- apiGroups: [""]
  resources: ["nodes"]
  verbs: ["get", "list", "watch"]
- apiGroups: [""]
  resources: ["nodes/stats"]
  verbs: ["get"]
EOF

# Create cluster role binding
kubectl apply -f - <<EOF
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: node-reader-binding
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: node-reader
subjects:
- kind: ServiceAccount
  name: monitoring-sa
  namespace: monitoring
EOF

Execution

kubectl get clusterroles,clusterrolebindings

Output

NAME                                           CREATED AT
clusterrole.rbac.../monitoring-binding     2m

ClusterRole is cluster-scoped, not namespace-scoped
Use for cluster admins and system components

Check permissions and debug RBAC

Verifies RBAC permissions and troubleshoots access issues

Code

# Check what user can do
kubectl auth can-i get pods -n development --as=system:serviceaccount:development:app-sa

# Check multiple permissions
kubectl auth can-i create deployments -n default
kubectl auth can-i delete pods -n default

# List all role bindings for user
kubectl get rolebinding,clusterrolebinding -A

# Describe role to see permissions
kubectl describe role pod-reader -n development

Execution

kubectl auth can-i get pods --as=system:serviceaccount:development:app-sa

Output

yes

can-i helps verify permissions before assigning access
Format: system:serviceaccount:namespace:name

Network Policies

Control network traffic with network policies

Create network policies for traffic control

Creates network policies to restrict traffic

Code

# Create deny-all network policy
kubectl apply -f - <<EOF
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: deny-all
  namespace: production
spec:
  podSelector: {}
  policyTypes:
  - Ingress
  - Egress
EOF

# Create allow policy for specific pods
kubectl apply -f - <<EOF
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-web-traffic
  namespace: production
spec:
  podSelector:
    matchLabels:
      app: web
  policyTypes:
  - Ingress
  ingress:
  - from:
    - podSelector:
        matchLabels:
          role: frontend
    ports:
    - protocol: TCP
      port: 80
EOF

Execution

kubectl get networkpolicies -n production

Output

NAME               POD-SELECTOR   AGE
deny-all           <none>         2m
allow-web-traffic  app=web        1m

NetworkPolicy requires network plugin with support
podSelector: {} matches all pods

Configure egress policies

Restricts outbound traffic from pods

Code

# Allow specific egress traffic
kubectl apply -f - <<EOF
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-egress
  namespace: production
spec:
  podSelector:
    matchLabels:
      app: api
  policyTypes:
  - Egress
  egress:
  - to:
    - podSelector:
        matchLabels:
          app: database
    ports:
    - protocol: TCP
      port: 5432
  - to:
    - namespaceSelector:
        matchLabels:
          name: kube-system
    ports:
    - protocol: UDP
      port: 53
EOF

Execution

kubectl describe networkpolicy allow-egress -n production

Output

Name:         allow-egress
Namespace:    production
Egress:
  To: app=database, port: 5432

Egress allows specifying allowed destination pods
DNS access usually required for pod-to-pod communication

Secrets and Secret Management

Securely store and manage sensitive data

Create and manage secrets

Creates secrets to store sensitive data

Code

# Create secret from literals
kubectl create secret generic db-secret \
  --from-literal=user=admin \
  --from-literal=password=secretpass

# Create secret from file
kubectl create secret generic app-config \
  --from-file=config.yaml

# Create docker registry secret
kubectl create secret docker-registry regcred \
  --docker-server=myregistry.com \
  --docker-username=user \
  --docker-password=pass

# List secrets
kubectl get secrets

Execution

kubectl get secrets

Output

NAME         TYPE                  DATA   AGE
db-secret    Opaque                2      2m
app-config   Opaque                1      1m

Secrets are base64-encoded, not encrypted by default
Consider using encryption at rest in production

Use secrets in pod specifications

Uses secrets as environment variables in pods

Code

# Create pod using secret as environment variables
kubectl apply -f - <<EOF
apiVersion: v1
kind: Pod
metadata:
  name: app-with-secret
spec:
  containers:
  - name: app
    image: myapp
    env:
    - name: DB_USER
      valueFrom:
        secretKeyRef:
          name: db-secret
          key: user
    - name: DB_PASSWORD
      valueFrom:
        secretKeyRef:
          name: db-secret
          key: password
  imagePullSecrets:
  - name: regcred
EOF

# Verify secret is applied
kubectl describe pod app-with-secret

Execution

kubectl get pod app-with-secret -o yaml

Output

env:
- name: DB_USER
  valueFrom:
    secretKeyRef:
      name: db-secret
      key: user

imagePullSecrets for private registry authentication
Secret data injected at runtime

View and update secrets

Views and manages secrets

Code

# View decoded secret
kubectl get secret db-secret -o jsonpath='{.data.password}' | base64 -d

# Edit secret
kubectl edit secret db-secret

# Delete secret
kubectl delete secret db-secret

# Get secret as YAML
kubectl get secret db-secret -o yaml

Execution

kubectl describe secret db-secret

Output

Name:         db-secret
Type:         Opaque
Data
user:    5 bytes
password: 10 bytes

Base64 decoding shows actual values
Be careful with secret exposure in logs

Advanced Operations

Logging, debugging, resource management, and advanced queries

Logging and Debugging

Collect and analyze logs for troubleshooting

Advanced logging and filtering

Gets detailed logs with filtering and streaming

Code

# Get logs from all containers in pod
kubectl logs pod-name --all-containers=true

# Get logs from previous pod instance
kubectl logs pod-name --previous

# Stream logs with timestamps
kubectl logs pod-name --timestamps=true -f

# Get logs from specific time range
kubectl logs pod-name --since=1h
kubectl logs pod-name --since-time='2025-02-28T10:00:00Z'

# Get logs from multiple pods
kubectl logs -f -l app=web --max-log-requests=10

# Tail specific number of lines
kubectl logs pod-name --tail=100

Execution

kubectl logs -f pod-name --tail=50

Output

2025-02-28T10:30:01.123Z INFO Starting application
2025-02-28T10:30:02.456Z INFO Connected to database

-f flag streams logs in real-time
--previous useful for crashed containers

Describe and inspect resources for debugging

Examines resource details and troubleshoots issues

Code

# Get full resource details
kubectl describe pod pod-name

# Get resource events
kubectl get events

# Watch resource for changes
kubectl get pods --watch

# Get events for specific resource
kubectl get events --field-selector involvedObject.name=pod-name

# Describe deployment to see replica status
kubectl describe deployment web-deployment

# Check resource conditions
kubectl get pod pod-name -o jsonpath='{.status.conditions}' | jq .

Execution

kubectl describe pod pod-name

Output

Name:         pod-name
Status:       Running
Conditions:
  Type    Status  Reason
  Ready   True    ContainersReady

Events show resource state changes
Conditions show readiness and health status

Advanced debugging with temporary containers

Creates temporary debugging containers

Code

# Create debug container in running pod
kubectl debug pod-name -it --image=busybox

# Debug specific container
kubectl debug pod-name -c container-name -it --image=busybox

# Debug with node access
kubectl debug node/node-name -it --image=ubuntu

# Create copy of pod for debugging
kubectl debug pod-name -it --copy-to=debug-pod

# Share process namespace for debugging
kubectl debug pod-name --target=container-name

Execution

kubectl debug pod-name -it --image=busybox

Output

Debugger started, running in pod-name ephemeral-debug-xyz
/ #

Debug containers have tools for troubleshooting
Copy-to creates standalone pod for destructive testing

JSONPath Queries and Output Formatting

Extract specific data with JSONPath queries

Extract data with JSONPath

Extracts specific fields using JSONPath syntax

Code

# Get pod names
kubectl get pods -o jsonpath='{.items[*].metadata.name}'

# Get pod IPs
kubectl get pods -o jsonpath='{.items[*].status.podIP}'

# Get image names from deployment
kubectl get deployment web -o jsonpath='{.spec.template.spec.containers[*].image}'

# Get container names and images
kubectl get pods -o jsonpath='{.items[*].spec.containers[*].name}'

# Format output with custom columns
kubectl get pods -o jsonpath='{range .items[*]}{.metadata.name}{"\t"}{.status.phase}{"\n"}{end}'

Execution

kubectl get pods -o jsonpath='{.items[*].metadata.name}'

Output

pod1 pod2 pod3

jsonpath is powerful for extracting nested data
Can combine with other tools like awk

Custom columns and wide output

Creates custom output columns for better readability

Code

# Define custom columns
kubectl get pods \
  -o custom-columns=NAME:.metadata.name,READY:.status.conditions[?(@.type=="Ready")].status,IMAGE:.spec.containers[0].image,IP:.status.podIP

# Format with custom columns shorthand
kubectl get pods --sort-by=.metadata.creationTimestamp

# Get pods with sorted output
kubectl get pods --sort-by='{.status.phase}'

# Wide format (standard custom columns)
kubectl get pods -o wide

Execution

kubectl get pods -o custom-columns=NAME:.metadata.name,STATUS:.status.phase,IP:.status.podIP

Output

NAME        STATUS    IP
pod1        Running   10.244.0.1
pod2        Running   10.244.0.2

Custom columns can format complex nested data
Sorting by specific fields helps organize output

Complex JSONPath queries with filters

Filters resources based on conditions in JSONPath

Code

# Get pods that are currently running
kubectl get pods -o jsonpath='{.items[?(@.status.phase=="Running")].metadata.name}'

# Get pods with specific label
kubectl get pods -o jsonpath='{.items[?(@.metadata.labels.tier=="web")].metadata.name}'

# Get containers with specific resource requests
kubectl get pods -o jsonpath='{.items[?(@.spec.containers[0].resources.requests.cpu)].metadata.name}'

# Format with line breaks for readability
kubectl get pods -o jsonpath='{range .items[*]}{.metadata.name}{"\t"}{.status.phase}{"\t"}{.status.podIP}{"\n"}{end}'

Execution

kubectl get pods -o jsonpath='{.items[?(@.status.phase=="Running")].metadata.name}'

Output

pod1 pod3

Filter expressions use @.field syntax
Complex queries can extract specific information

Dry-Run and Testing Patterns

Test changes before applying with dry-run

Preview changes with dry-run

Tests manifest application without creating resources

Code

# Preview pod creation
kubectl run test-pod --image=nginx --dry-run=client -o yaml

# Preview deployment creation
kubectl create deployment web --image=nginx --dry-run=server -o yaml

# Preview manifest application
kubectl apply -f deployment.yaml --dry-run=client

# Apply with server-side validation
kubectl apply -f deployment.yaml --dry-run=server

# Save dry-run output for review
kubectl apply -f - --dry-run=client -o yaml > deployment-preview.yaml <<EOF
apiVersion: apps/v1
kind: Deployment
metadata:
  name: web
spec:
  replicas: 3
  selector:
    matchLabels:
      app: web
  template:
    metadata:
      labels:
        app: web
    spec:
      containers:
      - name: nginx
        image: nginx:latest
EOF

Execution

kubectl apply -f deployment.yaml --dry-run=client

Output

deployment.apps/web created (dry run)

client: validates locally, server: validates on server
Useful for checking YAML syntax before applying

Validate resources and configurations

Validates manifests before actual deployment

Code

# Validate YAML syntax
kubectl apply -f deployment.yaml --dry-run=server

# Check if resource would be created
kubectl create deployment test --image=alpine --dry-run=client

# Validate all manifests in directory
kubectl apply -f ./manifests/ --dry-run=server

# Test with specific namespace
kubectl apply -f deployment.yaml --namespace=test --dry-run=client

# Get validation details
kubectl apply -f deployment.yaml --dry-run=server -o yaml

Execution

kubectl apply -f deployment.yaml --dry-run=server -o jsonpath='{.metadata.name}'

Output

web

Server-side dry-run catches API errors
Good for CI/CD pipeline validation

Test resource limits and constraints

Code

# Create pod with resource limits to test
kubectl apply -f - --dry-run=server <<EOF
apiVersion: v1
kind: Pod
metadata:
  name: resource-test
spec:
  containers:
  - name: app
    image: myapp
    resources:
      requests:
        cpu: 100m
        memory: 128Mi
      limits:
        cpu: 500m
        memory: 512Mi
EOF

# Check if quota allows creation
kubectl apply -f deployment.yaml --dry-run=server --validate=strict

# Test PVC binding
kubectl apply -f pvc.yaml --dry-run=server

Execution

echo '{"apiVersion":"v1","kind":"Pod","metadata":{"name":"test"},"spec":{"containers":[{"name":"app","image":"nginx"}]}}' | kubectl apply -f - --dry-run=server --validate=strict

Kubernetes

Getting Started

Kubernetes Basics

Accessibility

Best Practices

Common Errors

Keywords

Understand Kubernetes architecture

Check cluster nodes and capacity

Verify kubectl installation and context

Install and Configure kubectl

Accessibility

Best Practices

Common Errors

Keywords

Install kubectl on Linux

Configure kubectl with cloud clusters

Set up kubectl shell completion

Namespaces and Basic Navigation

Accessibility

Best Practices

Common Errors

Keywords

Explore and create namespaces

Set default namespace and switch between them

View all resources across namespaces

Cluster Management

Cluster Context and Configuration

Accessibility

Best Practices

Common Errors

Keywords

Manage kubeconfig contexts and clusters

Configure cluster authentication

Merge kubeconfig files and manage credentials

Cluster Information and Monitoring

Accessibility

Best Practices

Common Errors

Keywords

Check cluster health and component status

Monitor node resources and health

Check persistent volume and storage status

Node and Resource Management

Accessibility

Best Practices

Common Errors

Keywords

Cordon and drain nodes for maintenance

Add and remove node taints

Set resource quotas and limits per namespace

Pod Management

Creating and Listing Pods

Accessibility

Best Practices

Common Errors

Keywords

Create pods imperatively with kubectl run

Create pods declaratively with YAML manifests

List and filter pods

Inspecting and Debugging Pods

Accessibility

Best Practices

Common Errors

Keywords

Describe pods and view details

View pod logs and stream output

Interactive debugging and shell access

Deleting and Cleaning Up Pods

Accessibility

Best Practices

Common Errors

Keywords

Delete single and multiple pods

Graceful pod termination and force delete

Deployment Management

Creating Deployments

Accessibility

Best Practices

Common Errors
