Docker Compose

Getting Started

Installation & Setup

Install Docker Compose and verify installation on your system

Install Docker Compose on Linux

Downloads the Docker Compose binary for your system architecture and sets executable permissions

Code

curl -L "https://github.com/docker/compose/releases/latest/download/docker-compose-$(uname -s)-$(uname -m)" -o /usr/local/bin/docker-compose
chmod +x /usr/local/bin/docker-compose
docker-compose --version

Execution

Docker Compose version v2.25.0

Requires curl to be installed
Verify checksum for security
Use docker compose instead of docker-compose in v2

Verify Docker Compose Installation

Check Docker Compose version and review available commands

Code

docker compose version
docker compose --help

Execution

Docker Compose version v2.25.0, build something
Usage: docker compose [OPTIONS] COMMAND

Options:
  --version  Show the version and exit
  -f, --file FILE  Specify path to compose file
  -p, --project-name STRING  Set project name

Docker Compose v2 onwards uses 'docker compose' command
Legacy 'docker-compose' is deprecated

Project Structure & Configuration

Set up a Docker Compose project with proper directory structure

Create Docker Compose Project Directory

Create a basic project structure for Docker Compose with necessary directories

Code

mkdir my-app
cd my-app
touch compose.yml
mkdir -p app/src
mkdir -p data

Execution

$ tree my-app/
my-app/
├── compose.yml
├── app
│   └── src
└── data

Keep compose.yml at project root
Use consistent directory naming

Initialize with Example Compose File

Create minimal valid compose.yml and validate with config command

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: nginx:latest
5
    ports:
6
      - "80:80"

Execution

$ docker compose config
name: my-app
services:
  app:
    image: 'nginx:latest'
    ports:
      - mode: ingress
        target: 80
        published: "80"
        protocol: tcp
version: '3.9'

Version '3.9' is latest v3 stable
Always validate configuration

Version & Compatibility

Understand Docker Compose versions and compatibility requirements

Check Docker Compose and Docker Version

Verify both Docker Engine and Docker Compose versions are installed

Code

docker --version
docker compose version
docker compose version --format json

Execution

Docker version 25.0.0, build abcdef12
Docker Compose version v2.25.0, build build123
{"Version":"v2.25.0","ApiVersion":"1.46","Experimental":false}

Docker Engine 20.10+ required for Compose v2
Use JSON format for parsing in scripts

Version-Specific Features in Compose File

Use version 3.9+ features like healthcheck for container monitoring

Code

1
version: '3.9'
2
services:
3
  web:
4
    image: nginx:latest
5
    healthcheck:
6
      test: ["CMD", "curl", "-f", "http://localhost"]
7
      interval: 30s
8
      timeout: 10s

Execution

$ docker compose up -d
[+] Running 1/1
 ✔ Container my-app-web-1  Started

Version 3.8+ supports properties
Version 3.9 is feature-complete for most use cases

Basic Services

Service Definition & Images

Define services using images and configure basic service properties

Define Single Service with Image

Define a service using pre-built image with container naming and restart policy

Code

1
version: '3.9'
2
services:
3
  web:
4
    image: nginx:1.24
5
    container_name: my-nginx
6
    restart: always

Execution

$ docker compose up -d
[+] Running 1/1
 ✔ Container my-nginx  Created

Image format: name:tag or name:digest
container_name overrides auto-generated name

Multiple Services from Different Images

Define multiple interdependent services each using different official images

Code

1
version: '3.9'
2
services:
3
  web:
4
    image: nginx:latest
5
    container_name: web-server
6
  db:
7
    image: postgres:15
8
    container_name: database
9
  cache:
10
    image: redis:7-alpine
11
    container_name: redis-cache

Execution

$ docker compose up -d
[+] Running 3/3
 ✔ Container web-server     Created
 ✔ Container database       Created
 ✔ Container redis-cache   Created

Services communicate via service name automatically
Alpine variants use less disk space

Service with Image Pull Configuration

Pull image from private registry and always fetch latest version

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: myregistry.azurecr.io/myapp:v1.0
5
    pull_policy: always
6
    container_name: app-container

Execution

$ docker compose up
[+] Pulling 1/1
 ✔ myregistry.azurecr.io/myapp:v1.0 Pulled
[+] Running 1/1
 ✔ Container app-container  Created

pull_policy can be always, never, or missing
Missing policy (default) only pulls if image not local

Resource Constraints

Limit CPU and memory usage for services

Set Memory and CPU Limits

Set hard limits and soft reservations for container resources

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    deploy:
6
      resources:
7
        limits:
8
          cpus: '0.5'
9
          memory: 512M
10
        reservations:
11
          cpus: '0.25'
12
          memory: 256M

Execution

$ docker compose up -d
$ docker stats
CONTAINER ID   NAME     CPU %    MEM USAGE / LIMIT
abc123def456   app-1    0.5%    128M / 512M

Limits prevent container from using more than specified
Reservations guarantee minimum resources
Format: 0.5 = 50% of one CPU

Cascading Resource Configuration

Apply different resource constraints to different services

Code

1
version: '3.9'
2
services:
3
  database:
4
    image: mysql:8
5
    deploy:
6
      resources:
7
        limits:
8
          cpus: '1.0'
9
          memory: 1G
10
  cache:
11
    image: redis:7
12
    deploy:
13
      resources:
14
        limits:
15
          cpus: '0.5'
16
          memory: 256M

Execution

$ docker compose stats
NAME       CPU %   MEM USAGE / LIMIT
database   0.8%    512M / 1G
cache      0.2%    45M / 256M

Match resources to service requirements
Monitor actual usage to adjust limits

Restart Policies

Configure how containers restart on failure

Configure Restart Policy

Set restart policies to keep containers running or retry on failure

Code

1
version: '3.9'
2
services:
3
  web:
4
    image: nginx:latest
5
    restart: always
6
  app:
7
    image: node:18
8
    restart: on-failure
9
    deploy:
10
      restart_policy:
11
        condition: on-failure
12
        max_attempts: 3
13
        delay: 5s

Execution

$ docker compose up -d
[+] Running 2/2
 ✔ Container web-1  Started
 ✔ Container app-1  Started

always: always restart unless explicitly stopped
on-failure: restart only if exit code is non-zero
max_attempts: limit retry count

Restart Policy with Exponential Backoff

Retry with limited attempts and timeout window using deploy configuration

Code

1
version: '3.9'
2
services:
3
  api:
4
    image: myapp:latest
5
    deploy:
6
      restart_policy:
7
        condition: on-failure
8
        max_attempts: 5
9
        delay: 1s
10
        window: 120s

Execution

$ docker compose logs api
api-1 | Starting service...
api-1 | Service started

window: only count failures within this timeframe
Prevents infinite restart loops

Ports & Networking

Port Mapping & Exposure

Map container ports to host ports and expose services

Basic Port Mapping

Map host port 8080 to container port 80, and 8443 to 443

Code

1
version: '3.9'
2
services:
3
  web:
4
    image: nginx:latest
5
    ports:
6
      - "8080:80"
7
      - "8443:443"

Execution

$ docker compose up -d
$ curl http://localhost:8080
<!DOCTYPE html>
<html>
<head><title>Welcome to nginx!</title></head>

Format: host:container
Can specify IP: 127.0.0.1:8080:80

Multiple Services with Port Mapping

Expose multiple services on different ports

Code

1
version: '3.9'
2
services:
3
  web:
4
    image: nginx:latest
5
    ports:
6
      - "80:80"
7
  api:
8
    image: node:18
9
    ports:
10
      - "3000:3000"
11
  db:
12
    image: postgres:15
13
    ports:
14
      - "5432:5432"

Execution

$ docker compose ps
NAME      IMAGE          PORTS
web-1     nginx:latest   0.0.0.0:80->80/tcp
api-1     node:18        0.0.0.0:3000->3000/tcp
db-1      postgres:15    0.0.0.0:5432->5432/tcp

Each service can have multiple port mappings
Default protocol is tcp, can specify udp

Port Mapping with Protocol Specification

Specify protocol (tcp/udp) and use verbose port syntax

Code

1
version: '3.9'
2
services:
3
  dns:
4
    image: coredns:latest
5
    ports:
6
      - "53:53/udp"
7
      - "53:53/tcp"
8
  web:
9
    image: nginx:latest
10
    ports:
11
      - target: 80
12
        published: 8080
13
        protocol: tcp

Execution

$ docker compose ps
NAME    IMAGE               PORTS
dns-1   coredns:latest      0.0.0.0:53->53/tcp, 0.0.0.0:53->53/udp
web-1   nginx:latest        0.0.0.0:8080->80/tcp

Default protocol is tcp
Verbose syntax allows more control

Network Configuration

Configure custom networks and manage service connectivity

Define Custom Networks

Define custom networks and assign services to them for isolation

Code

1
version: '3.9'
2
services:
3
  web:
4
    image: nginx:latest
5
    networks:
6
      - frontend
7
  api:
8
    image: node:18
9
    networks:
10
      - frontend
11
      - backend
12
  db:
13
    image: postgres:15
14
    networks:
15
      - backend
16
networks:
17
  frontend:
18
    driver: bridge
19
  backend:
20
    driver: bridge

Execution

$ docker compose up -d
[+] Creating network my-app_frontend
[+] Creating network my-app_backend
$ docker network ls
NETWORK ID    NAME               DRIVER
abc123        my-app_frontend    bridge
def456        my-app_backend     bridge

Services on same network can communicate via service name
Services on different networks require linking

External Network Integration

Connect services to external networks created outside Compose

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    networks:
6
      - shared-network
7
networks:
8
  shared-network:
9
    external: true
10
    name: production-network

Execution

$ docker compose up -d
[+] Running 1/1
 ✔ Container app-1  Started
$ docker network inspect production-network
[
  {
    "Name": "production-network",
    "Containers": {
      "abc123...": {
        "Name": "app-1"
      }
    }
  }
]

External networks must exist before docker compose up
Useful for multi-compose-file deployments

DNS & Service Discovery

Configure DNS and internal service discovery

Service DNS Resolution

Services can discover each other using service name or hostname

Code

1
version: '3.9'
2
services:
3
  web:
4
    image: nginx:latest
5
    hostname: webserver
6
  api:
7
    image: node:18
8
    hostname: apiserver

Execution

$ docker compose exec api curl http://webserver
<!DOCTYPE html>
<html>
<head><title>Welcome to nginx!</title></head>

Default: service name is used for DNS
Hostname overrides service name if specified

Custom DNS Servers

Override default DNS servers and search domains

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    dns:
6
      - 8.8.8.8
7
      - 8.8.4.4
8
    dns_search:
9
      - example.com
10
      - internal.local

Execution

$ docker compose exec app cat /etc/resolv.conf
nameserver 8.8.8.8
nameserver 8.8.4.4
search example.com internal.local

Useful for internal DNS or custom resolvers
Multiple servers provide redundancy

Volumes & Storage

Volume Types & Mounting

Work with named volumes, anonymous volumes, and bind mounts

Named Volumes for Data Persistence

Create named volumes for persistent data that survives container removal

Code

1
version: '3.9'
2
services:
3
  db:
4
    image: postgres:15
5
    volumes:
6
      - db_data:/var/lib/postgresql/data
7
  cache:
8
    image: redis:7
9
    volumes:
10
      - cache_data:/data
11
volumes:
12
  db_data:
13
  cache_data:

Execution

$ docker compose up -d
$ docker volume ls
DRIVER    VOLUME NAME
local     my-app_db_data
local     my-app_cache_data

Named volumes are managed by Docker
Data persists when containers are removed
Can be used across containers

Bind Mounts for Development

Mount local directories into container for live development

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    working_dir: /app
6
    volumes:
7
      - ./src:/app/src
8
      - ./package.json:/app/package.json
9
      - ./package-lock.json:/app/package-lock.json
10
    ports:
11
      - "3000:3000"

Execution

$ docker compose up -d
$ ls /app
src  package.json  package-lock.json

Changes on host immediately visible in container
Perfect for development workflows
Use relative paths for portability

Anonymous Volumes and Read-Only Volumes

Use anonymous volumes, read-only mounts, and shared writable volumes

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    volumes:
6
      - /tmp
7
      - ./config.json:/app/config.json:ro
8
      - shared_data:/shared:rw
9
volumes:
10
  shared_data:

Anonymous volumes are cleaned on down
ro = read-only, rw = read-write
:ro prevents accidental modifications

Volume Mount Options

Use long-form volume syntax for granular control

Code

1
version: '3.9'
2
services:
3
  db:
4
    image: postgres:15
5
    volumes:
6
      - type: volume
7
        source: db_data
8
        target: /var/lib/postgresql/data
9
        volume:
10
          nocopy: true
11
      - type: bind
12
        source: ./init-scripts
13
        target: /docker-entrypoint-initdb.d
14
        read_only: true
15
volumes:
16
  db_data:

Execution

$ docker compose up -d
$ docker compose exec db ls /var/lib/postgresql/data
base global pg_hba.conf

nocopy: don't copy volume content from existing data
read_only: mount as read-only
More explicit than shorthand

Volume Management & Cleanup

Manage and maintain Docker Compose volumes

List and Inspect Volumes

List volumes created by Compose and inspect their properties

Code

docker compose volume ls
docker volume inspect my-app_db_data
docker volume inspect my-app_db_data --format='{{json .Mountpoint}}'

Execution

DRIVER    VOLUME NAME
local     my-app_db_data

[
  {
    "Name": "my-app_db_data",
    "Driver": "local",
    "Mountpoint": "/var/lib/docker/volumes/my-app_db_data/_data"
  }
]

Volumes persist after docker compose down
Mountpoint shows where data is stored

Clean Up Volumes

Remove volumes when stopping containers or clean unused volumes

Code

docker compose down -v
docker volume rm my-app_db_data
docker volume prune -f

Execution

Removing stopped containers...
Removing named volumes...
Deleted Volumes:
my-app_db_data

Deleted Volumes:
my-app_cache_data

down -v removes named volumes declared in compose file
prune removes all unused volumes
Use force flag to skip confirmation

Environment & Configuration

Environment Variables

Set and manage environment variables for services

Environment Variables in Compose File

Define environment variables directly in compose.yml

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    environment:
6
      NODE_ENV: production
7
      LOG_LEVEL: debug
8
      DATABASE_URL: postgres://user:pass@db:5432/mydb
9
      API_PORT: 3000

Execution

$ docker compose exec app env
NODE_ENV=production
LOG_LEVEL=debug
DATABASE_URL=postgres://user:pass@db:5432/mydb
API_PORT=3000

Variables are set when container starts
Application code reads these variables

Environment Files (.env)

Load environment variables from .env files and reference them in compose

Code

1
version: '3.9'
2
services:
3
  db:
4
    image: postgres:15
5
    env_file:
6
      - .env.database
7
      - .env.common
8
  app:
9
    image: node:18
10
    env_file: .env
11
    environment:
12
      NODE_ENV: ${NODE_ENV}

Execution

$ cat .env
NODE_ENV=production
API_KEY=sk-12345
$ docker compose up -d
$ docker compose exec app echo $NODE_ENV
production

Files are loaded in order, later overrides earlier
Use ${VAR} syntax to reference variables
.env in current directory loaded automatically

Variable Substitution and Defaults

Substitute variables with defaults using ${VAR:-default} syntax

Code

1
version: '3.9'
2
services:
3
  web:
4
    image: nginx:${NGINX_VERSION:-latest}
5
    ports:
6
      - "${HOST_PORT:-80}:80"
7
  api:
8
    image: node:18
9
    environment:
10
      DATABASE_HOST: ${POSTGRES_HOST}
11
      DATABASE_PORT: ${POSTGRES_PORT:-5432}
12
      SECRET_KEY: ${SECRET_KEY}

Execution

$ NGINX_VERSION=1.24 docker compose up
$ docker compose config --resolve-image-digests
version: '3.9'
services:
  web:
    image: 'nginx:1.24'
    ports:
      - mode: ingress
        target: 80
        published: "80"

:- provides default if variable not set
Define in .env or export before docker compose
Use in any field

Per-Service Environment Variables

Set different environment variables for each service with .env files

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    env_file: .env.app
6
    environment:
7
      NODE_ENV: ${NODE_ENV:-development}
8
  db:
9
    image: postgres:15
10
    env_file: .env.database
11
    environment:
12
      POSTGRES_DB: ${DB_NAME:-mydb}
13
      POSTGRES_USER: ${DB_USER}
14
      POSTGRES_PASSWORD: ${DB_PASSWORD}

Execution

$ docker compose exec db psql -U ${DB_USER} -d ${DB_NAME}
psql (15.1)
Type "help" for help.

Each service can have its own .env file
Can mix env_file and environment directives

Configuration Files & Secrets

Manage configuration files and sensitive data

Mount Configuration Files as Volumes

Mount configuration files into containers as read-only volumes

Code

1
version: '3.9'
2
services:
3
  nginx:
4
    image: nginx:latest
5
    volumes:
6
      - ./nginx.conf:/etc/nginx/nginx.conf:ro
7
      - ./conf.d:/etc/nginx/conf.d:ro
8
  app:
9
    image: node:18
10
    volumes:
11
      - ./config/app.json:/app/config/app.json:ro

Execution

$ docker compose exec nginx cat /etc/nginx/nginx.conf
# nginx configuration

:ro makes mount read-only
Prevents accidental modifications

Use Environment Files for Secrets

Store secrets in separate .env files and load them securely

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    env_file:
6
      - .env
7
      - .env.secrets
8
    environment:
9
      DATABASE_PASSWORD: ${DB_PASSWORD}
10
      API_KEY: ${API_KEY}

Execution

$ cat .env.secrets
DB_PASSWORD=super_secret_password_123
API_KEY=sk-abc123def456

Add .env.secrets to .gitignore
Keep secrets out of version control
Consider using Docker secrets for production

Build Configuration

Build from Dockerfile

Build custom images from Dockerfile during compose up

Basic Build Configuration

Build Docker image from Dockerfile in current directory

Code

1
version: '3.9'
2
services:
3
  app:
4
    build: .
5
    ports:
6
      - "3000:3000"
7
    environment:
8
      NODE_ENV: development

Execution

$ docker compose build
[+] Building 12.3s (15/15) FINISHED
 => [internal] load build definition from Dockerfile
 => [stage-0 1/5] FROM node:18
 => [stage-0 2/5] WORKDIR /app
 => [stage-0 3/5] COPY package*.json ./
 => [stage-0 4/5] RUN npm ci
 => [stage-0 5/5] RUN npm run build
 => exporting to image
Successfully tagged my-app-app:latest

build: . uses Dockerfile in current directory
Image tagged as project_service:latest

Build with Specific Dockerfile and Context

Build from different Dockerfile with custom context and build arguments

Code

1
version: '3.9'
2
services:
3
  app:
4
    build:
5
      context: ./src
6
      dockerfile: Dockerfile.prod
7
      args:
8
        NODE_ENV: production
9
        BUILD_VERSION: 1.0.0
10
  api:
11
    build:
12
      context: ./api-service
13
      dockerfile: Dockerfile

Execution

$ docker compose build
[+] Building 25.1s (20/20) FINISHED
 => [internal] load build definition from ./src/Dockerfile.prod
 => [stage-0 1/8] FROM node:18
 => Setting build args: NODE_ENV=production, BUILD_VERSION=1.0.0
Successfully tagged my-app-app:latest

context: directory with Dockerfile
dockerfile: specify non-standard Dockerfile name
args: pass build-time arguments

Multi-Stage Build with Compose

Use multi-stage build to create smaller final images

Code

1
version: '3.9'
2
services:
3
  app:
4
    build:
5
      context: .
6
      dockerfile: Dockerfile.multistage
7
      target: runtime
8
      args:
9
        PYTHON_VERSION: 3.11

Execution

$ docker compose build
[+] Building 15.2s (25/25) FINISHED
 => [builder 1/8] FROM python:3.11
 => [builder 2/8] WORKDIR /build
 => [builder 3/8] COPY . .
 => [builder 4/8] RUN pip install -r requirements.txt
 => [runtime 1/3] FROM python:3.11-slim
 => [runtime 2/3] COPY --from=builder /build/app /app
Successfully tagged my-app-app:latest

target: build specific stage
Copy artifacts from builder stage to reduce size

Build Arguments and Cache

Pass arguments to builds and manage build cache

Build Arguments in Dockerfile

Pass build-time arguments that become available as ARG in Dockerfile

Code

1
version: '3.9'
2
services:
3
  app:
4
    build:
5
      context: .
6
      args:
7
        - BUILD_DATE=2026-02-28
8
        - VCS_REF=abc123def456
9
        - VERSION=1.0.0

Execution

$ docker compose build
[+] Building 10.5s (8/8) FINISHED
 => [internal] load build definition
 => [stage-0 1/3] FROM node:18
 => [stage-0 2/3] RUN echo "Version: 1.0.0"
 => [stage-0 3/3] RUN echo "Built: 2026-02-28"

Args are passed during build phase only
Use ARG instruction in Dockerfile
Environment-specific configuration

Cache Management

Skip Docker layer cache or force rebuilding with fresh images

Code

docker compose build --no-cache
docker compose build --no-cache app
docker compose build --pull

Execution

$ docker compose build --no-cache
[+] Building 30.2s (15/15) FINISHED
 => [stage-0 1/5] FROM node:18
 => [stage-0 2/5] WORKDIR /app
 => [stage-0 3/5] COPY . .  [cached]
 => [stage-0 4/5] RUN npm ci [not cached]
Successfully tagged my-app-app:latest

--no-cache: rebuild all layers
--pull: always pull base images
Useful when dependencies change

Advanced Features

Health Checks & Monitoring

Configure health checks to monitor container status

Implement Health Checks

Define health checks to verify container is running correctly

Code

1
version: '3.9'
2
services:
3
  web:
4
    image: nginx:latest
5
    healthcheck:
6
      test: ["CMD", "curl", "-f", "http://localhost"]
7
      interval: 30s
8
      timeout: 10s
9
      retries: 3
10
      start_period: 40s
11
  api:
12
    image: node:18
13
    healthcheck:
14
      test: ["CMD-SHELL", "curl -f http://localhost:3000/health || exit 1"]
15
      interval: 30s
16
      timeout: 10s
17
      retries: 3

Execution

$ docker compose up -d
$ docker compose ps
NAME    IMAGE         STATUS
web-1   nginx:latest  Up 30s (health: starting)
api-1   node:18       Up 25s (health: healthy)

test: command to run (CMD or CMD-SHELL)
start_period: grace period before health checks
Exit code 0 = healthy, non-zero = unhealthy

Depends On with Health Checks

Wait for dependent service to pass health check before starting

Code

1
version: '3.9'
2
services:
3
  db:
4
    image: postgres:15
5
    healthcheck:
6
      test: ["CMD-SHELL", "pg_isready -U postgres"]
7
      interval: 10s
8
      timeout: 5s
9
      retries: 5
10
  app:
11
    image: node:18
12
    depends_on:
13
      db:
14
        condition: service_healthy

Execution

$ docker compose up
db-1 | PostgreSQL accepting connections
app-1 | Waiting for service_healthy condition on db

condition: service_healthy waits for passing health check
Prevents startup order issues

Service Dependencies

Define startup order and dependencies between services

Basic Service Dependencies

Specify that app depends on db and cache services

Code

1
version: '3.9'
2
services:
3
  db:
4
    image: postgres:15
5
  cache:
6
    image: redis:7
7
  app:
8
    image: node:18
9
    depends_on:
10
      - db
11
      - cache

Execution

$ docker compose up
[+] Running 3/3
 ✔ Container pg-1     Started
 ✔ Container redis-1  Started
 ✔ Container app-1    Started

Services listed as dependencies start first
Does not wait for service to be ready, only for container to start

Conditional Dependency with Service Ready

Wait for service to be healthy before starting dependent service

Code

1
version: '3.9'
2
services:
3
  db:
4
    image: postgres:15
5
    healthcheck:
6
      test: ["CMD-SHELL", "pg_isready -U postgres"]
7
      interval: 5s
8
      timeout: 5s
9
      retries: 5
10
  api:
11
    image: node:18
12
    depends_on:
13
      db:
14
        condition: service_healthy

Execution

$ docker compose up -d
db-1 | PostgreSQL started
api-1 waiting for db...
api-1 | Connected to database

Requires health check on dependency
Prevents connection errors at startup

Labels & Metadata

Add metadata labels to containers and services

Add Labels to Services

Attach metadata labels to services for organization and tooling

Code

1
version: '3.9'
2
services:
3
  web:
4
    image: nginx:latest
5
    labels:
6
      com.example.description: "Web server"
7
      com.example.version: "1.0"
8
      com.example.tier: "frontend"
9
  app:
10
    image: node:18
11
    labels:
12
      com.example.description: "API server"
13
      com.example.version: "2.0"
14
      com.example.tier: "backend"

Execution

$ docker inspect my-app-web-1 --format='{{json .Config.Labels}}'
{"com.example.description":"Web server","com.example.tier":"frontend","com.example.version":"1.0"}

Use reverse domain notation for label keys
Can be inspected with docker inspect
Used by monitoring and orchestration tools

Override Entrypoint & Command

Override default container command and entrypoint

Override Command

Override default CMD with custom commands

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    working_dir: /app
6
    command: npm start
7
    volumes:
8
      - ./app:/app
9
  worker:
10
    image: node:18
11
    working_dir: /app
12
    command: npm run worker
13
    volumes:
14
      - ./app:/app

Execution

$ docker compose up -d
app-1 | npm start
app-1 | Server listening on port 3000

command: overrides CMD from Dockerfile
Each service can have different command

Override Entrypoint

Completely override container entrypoint

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: myapp:latest
5
    entrypoint: /bin/bash
6
    command: -c "npm install && npm start"

Execution

$ docker compose up
app-1 | /bin/bash -c npm install && npm start

entrypoint: completely replaces ENTRYPOINT from Dockerfile
Use for different execution paths

Docker Compose Commands

Lifecycle Management (up/down/stop)

Start, stop, and manage container lifecycle

Start Services (docker compose up)

Start services defined in compose file

Code

docker compose up
docker compose up -d
docker compose up --build
docker compose up -f compose.yml -f docker-compose.prod.yml

Execution

[+] Running 3/3
 ✔ Container pg-1      Started
 ✔ Container redis-1   Started
 ✔ Container app-1     Started

up: creates and starts services
-d: detached mode (background)
--build: build before starting

Stop and Remove Services (docker compose down)

Stop services or remove containers, networks, and optionally volumes

Code

docker compose stop
docker compose down
docker compose down -v
docker compose down --rmi all

Execution

Stopping my-app-app-1 ... done
Removing my-app-app-1 ... done
Removing network my-app_default

stop: stops containers (can restart)
down: removes containers, networks
-v: also remove named volumes
--rmi all: remove created images

Pause and Resume Services

Pause containers or forcefully kill them

Code

docker compose pause
docker compose unpause
docker compose kill

Execution

Pausing my-app-app-1 ... done
Unpausing my-app-app-1 ... done
Killing my-app-app-1 ... done

pause: freezes containers (keeps in memory)
unpause: resumes paused containers
kill: sends SIGKILL (force termination)

Execution & Interaction (exec/run/logs)

Run commands in containers and view logs

Execute Commands in Running Container

Run commands in already running containers

Code

docker compose exec app npm test
docker compose exec -u root app apt-get update
docker compose exec db psql -U postgres -d mydb
docker compose exec -it app /bin/bash

Execution

> npm test

PASS __tests__/app.test.js
  App
    ✓ should start successfully (142ms)

Test Suites: 1 passed
Tests: 1 passed

-i: interactive
-t: allocate pseudo-terminal
-u: run as specific user

Run One-Off Container

Run temporary containers to execute commands

Code

docker compose run app npm install
docker compose run --rm worker node scripts/migrate.js
docker compose run -e NODE_ENV=test app npm test

Execution

> npm install
added 150 packages in 45s

run: starts new container for command
--rm: automatically remove container after exit
-e: set environment variables

View Container Logs

View output logs from containers

Code

docker compose logs
docker compose logs app
docker compose logs -f app
docker compose logs --tail=100 app
docker compose logs --timestamps app

Execution

app-1     | npm start
app-1     | Server listening on port 3000
app-1     | GET /api/health 200 12ms
app-1     | POST /api/data 201 45ms

-f: follow logs in real-time
--tail: show last N lines
--timestamps: add timestamps to logs

Status & Information (ps/config/port)

Check container status and view configurations

List Running Containers (docker compose ps)

List all containers defined in compose file

Code

docker compose ps
docker compose ps --all
docker compose ps --format json
docker compose ps -a

Execution

NAME      IMAGE            PORTS                    STATUS
app-1     node:18          0.0.0.0:3000->3000/tcp   Up 2 minutes (healthy)
db-1      postgres:15      0.0.0.0:5432->5432/tcp   Up 3 minutes
cache-1   redis:7          6379/tcp                 Up 2 minutes 45s

Shows running containers by default
-a: include stopped containers
--format json: output JSON

View Merged Configuration

Display merged compose configuration from all files

Code

docker compose config
docker compose config --resolve-image-digests
docker compose config --format json

Execution

name: my-app
services:
  app:
    image: 'node:18'
    ports:
      - mode: ingress
        target: 3000
        published: "3000"
        protocol: tcp
version: '3.9'

Shows final resolved configuration
Useful for debugging variable substitution
--format json: output as JSON

Get Service Port Mappings

Show public port for specific container port

Code

docker compose port app 3000
docker compose port db 5432
docker compose port --index=2 app 3000

Execution

0.0.0.0:3000
0.0.0.0:5432

Useful for discovering mapped ports
--index: for multiple instances

Build & Push Commands

Build and manage Docker images

Build Services

Build Docker images from specified Dockerfiles

Code

docker compose build
docker compose build app
docker compose build --no-cache
docker compose build --pull

Execution

[+] Building 12.3s (15/15) FINISHED
 => [app internal] load build definition from Dockerfile
 => [app stage-0 1/5] FROM node:18
 => [app stage-0 2/5] WORKDIR /app
 => [app stage-0 3/5] COPY package*.json ./
 => [app stage-0 4/5] RUN npm ci
 => [app stage-0 5/5] RUN npm run build
 => [app] exporting to image
Successfully tagged my-app-app:latest

Builds all services with build context by default
--no-cache: skip layer cache
--pull: always update base images

Push Images to Registry

Push images to Docker registry

Code

docker compose push
docker compose push app
docker compose push myregistry.azurecr.io/myapp:v1.0

Execution

Pushing app (myregistry.azurecr.io/myapp:v1.0)...
The push refers to repository [myregistry.azurecr.io/myapp]
abc123: Pushed
def456: Pushed
ghi789: Pushed
v1.0: digest: sha256:1234567890abcdef

Requires image to be built first
authenticate to registry before pushing

Network & Security

Network Modes & Links

Configure network modes and inter-service communication

Service Discovery via Service Name

Services communicate automatically using service names as hostnames

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    environment:
6
      DATABASE_URL: postgresql://postgres:5432/mydb
7
  postgres:
8
    image: postgres:15
9
    environment:
10
      POSTGRES_DB: mydb
11
      POSTGRES_PASSWORD: password

Execution

$ docker compose up -d
$ docker compose exec app ping postgres
PING postgres (172.18.0.2): 56 data bytes
64 bytes from 172.18.0.2: seq=0 ttl=64 time=0.123 ms

Service names resolve to container IPs
Works across custom networks
Default bridge network

Legacy Service Links

Create DNS aliases for services (legacy feature)

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    links:
6
      - postgres:database
7
      - redis:cache
8
    environment:
9
      DATABASE_URL: postgresql://database:5432
10
  postgres:
11
    image: postgres:15
12
  redis:
13
    image: redis:7

Execution

$ docker compose exec app cat /etc/hosts
127.0.0.1   localhost
172.18.0.2  database
172.18.0.3  cache

Deprecated in favor of custom networks
Still works for backwards compatibility
Not recommended for new projects

User Permissions & Security

Configure user context and security options

Run Services as Specific User

Run containers as specific user instead of root

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    user: "1000:1000"
6
    working_dir: /app
7
    volumes:
8
      - ./src:/app/src
9
  worker:
10
    image: node:18
11
    user: node
12
    working_dir: /app

Format: uid:gid or username
Improves security and file permissions
Prevents permission issues with mounted volumes

Security Options

Configure security options and capabilities

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    security_opt:
6
      - no-new-privileges:true
7
  privileged:
8
    image: ubuntu:latest
9
    privileged: false
10
    cap_add:
11
      - NET_ADMIN
12
    cap_drop:
13
      - ALL

Execution

$ docker compose exec app id
uid=0(root) gid=0(root) groups=0(root)

no-new-privileges: prevent privilege escalation
CAP_ADD: add specific Linux capabilities
CAP_DROP: remove capabilities

External Networks & Scaling

Connect to external networks and scale services

Scale Services

Run multiple instances of a service for horizontal scaling

Code

docker compose up -d --scale app=3
docker compose up -d --scale worker=5 --scale app=2

Execution

[+] Running 8/8
 ✔ Container app-1       Started
 ✔ Container app-2       Started
 ✔ Container app-3       Started
 ✔ Container worker-1    Started
 ✔ Container worker-2    Started
 ✔ Container worker-3    Started
 ✔ Container worker-4    Started
 ✔ Container worker-5    Started

--scale service=count
Each instance gets unique name (app-1, app-2, etc.)
Use with load balancer for traffic distribution

Connect Multiple Compose Projects

Connect services to external networks shared across projects

Code

1
version: '3.9'
2
services:
3
  app:
4
    image: node:18
5
    networks:
6
      - monolith
7
      - external-network
8
networks:
9
  monolith:
10
    driver: bridge
11
  external-network:
12
    external: true
13
    name: company-network

Execution

$ docker compose up -d
[+] Running 1/1
 ✔ Container app-1  Started
$ docker network inspect company-network
[
  {
    "Containers": {
      "abc123": {"Name": "app-1"}
    }
  }
]

External networks must be created beforehand
Multiple compose files can share networks
Enables multi-service orchestration

Docker Compose

Getting Started

Installation & Setup

Accessibility

Keywords

Install Docker Compose on Linux

Verify Docker Compose Installation

Project Structure & Configuration

Accessibility

Keywords

Create Docker Compose Project Directory

Initialize with Example Compose File

Version & Compatibility

Accessibility

Keywords

Check Docker Compose and Docker Version

Version-Specific Features in Compose File

Basic Services

Service Definition & Images

Accessibility

Keywords

Define Single Service with Image

Multiple Services from Different Images

Service with Image Pull Configuration

Resource Constraints

Accessibility

Keywords

Set Memory and CPU Limits

Cascading Resource Configuration

Restart Policies

Accessibility

Keywords

Configure Restart Policy

Restart Policy with Exponential Backoff

Ports & Networking

Port Mapping & Exposure

Accessibility

Keywords

Basic Port Mapping

Multiple Services with Port Mapping

Port Mapping with Protocol Specification

Network Configuration

Accessibility

Keywords

Define Custom Networks

External Network Integration

DNS & Service Discovery

Accessibility

Keywords

Service DNS Resolution

Custom DNS Servers

Volumes & Storage

Volume Types & Mounting

Accessibility

Keywords

Named Volumes for Data Persistence

Bind Mounts for Development

Anonymous Volumes and Read-Only Volumes

Volume Mount Options

Volume Management & Cleanup

Accessibility

Keywords

List and Inspect Volumes

Clean Up Volumes

Environment & Configuration

Environment Variables

Accessibility

Keywords

Environment Variables in Compose File

Environment Files (.env)

Variable Substitution and Defaults

Per-Service Environment Variables

Configuration Files & Secrets

Accessibility

Keywords

Mount Configuration Files as Volumes

Use Environment Files for Secrets

Build Configuration

Build from Dockerfile

Accessibility
